24000W Standard Air Cooled Condenser In Refrigeration , Corrosion Resistance DD-37.2/200

China 24000W Standard Air Cooled Condenser In Refrigeration , Corrosion Resistance DD-37.2/200 supplier
24000W Standard Air Cooled Condenser In Refrigeration , Corrosion Resistance DD-37.2/200 supplier 24000W Standard Air Cooled Condenser In Refrigeration , Corrosion Resistance DD-37.2/200 supplier

Large Image :  24000W Standard Air Cooled Condenser In Refrigeration , Corrosion Resistance DD-37.2/200

Product Details:

Place of Origin: CHINA
Brand Name: RFJ
Certification: CE
Model Number: DD-37.2/200

Payment & Shipping Terms:

Minimum Order Quantity: 5
Price: discussed
Packaging Details: wooden packaging
Delivery Time: 10-15DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000PCS
Contact Now
Detailed Product Description
Refrigerating Capacity: 37200W Nominal Area: 200m2
Volume: 32.3L Inlet/Outlet Tube Of Refrigerant: 25-50
Quantity: 4N Diameter Of Fan: 500mm
Voltage: 380V Power: 4*414W
Air Volume: 24000W Range: 15m

Standard type air cooling machine size parameters
Model Length Width Height Position size of the mounting hole Drainage to take over the outer diameter Space
L B H D E E1 E2 E3 F W
DL-2/10 670 460 485 360 455 / / / 87 G1" 300
DD-1.2/7
DL-6.2/30 1300 460 485 360 1085 / / / 87 G1" 300
DD-3.7/22
DJ-2.6/15
DL-12.3/60 1750 460 580 360 1455 / / / 107 G1" 350
DD-7.0/40
DJ-5.1/30
DL-16.4/80 1920 580 630 470 1625 800 / / 107 G1" 400
DD-11.2/60
DJ-6.8/40
DL-28/125 2420 580 680 470 2025 665 665 / 107 G1" 450
DD-18.7/100
DJ-11.6/70
DL-32.8/160 2720 580 680 470 2425 800 800 / 107 G1" 500
DD-22.3/120
DJ-14.3/85
DL-37.9/185 3120 580 680 470 2825 700 700 700 107 G1.5" 500
DD-26.2/140
DJ-17.9/105
DL-53.3/260 3520 630 680 520 3225 800 800 800 107 G2" 500
DD-37.2/200
DJ-23.9/140
DL-83.6/410 3520 680 1020 570 3225 800 800 800 107 G2" 610
DD-57.9/310
DJ-35.8/210

Product Features:



D series air cooler is a complete library of cooling cooling equipment freon refrigeration unit used;by the use of temperature to sub-divided into DL,DD,DJ three series,can be separately applied to different storage temperature ,DL type air cooler mainly applied to the preservation of about 0℃,DD type air cooler is mainly applied to the refrigerator of -18℃,DJ type cooling fan is mainly applied to -25℃ or less frozen library.



The series has the following characteristics:



1.Designed for fresh,chilled and frozen;
2.The shell is made of high quality steel,powder coated,corrosion resistance,aesthetic appearance;
3.High-quality stainless steel electric heating tube evenly distributed in the coil,good defrosting effect, defrost using electric heating tube and finned aluminum casing hole close,easy to heat,long life;
4.Coil using the wrong row or parallel manner,using a mechanical expander, brass and aluminum so closely,good effect of heat transfer;
5.Cooler design width reasonable, blades and aluminum fin spacing is greater than 1/3 diameter of the blades to ensure there is enough effective air flow;



Standard type air cooling machine size parameters
Model Length Width Height Position size of the mounting hole Drainage to take over the outer diameter Space
L B H D E E1 E2 E3 F W
DL-2/10 670 460 485 360 455 / / / 87 G1" 300
DD-1.2/7
DL-6.2/30 1300 460 485 360 1085 / / / 87 G1" 300
DD-3.7/22
DJ-2.6/15
DL-12.3/60 1750 460 580 360 1455 / / / 107 G1" 350
DD-7.0/40
DJ-5.1/30
DL-16.4/80 1920 580 630 470 1625 800 / / 107 G1" 400
DD-11.2/60
DJ-6.8/40
DL-28/125 2420 580 680 470 2025 665 665 / 107 G1" 450
DD-18.7/100
DJ-11.6/70
DL-32.8/160 2720 580 680 470 2425 800 800 / 107 G1" 500
DD-22.3/120
DJ-14.3/85
DL-37.9/185 3120 580 680 470 2825 700 700 700 107 G1.5" 500
DD-26.2/140
DJ-17.9/105
DL-53.3/260 3520 630 680 520 3225 800 800 800 107 G2" 500
DD-37.2/200
DJ-23.9/140
DL-83.6/410 3520 680 1020 570 3225 800 800 800 107 G2" 610
DD-57.9/310
DJ-35.8/210
