Payment & Shipping Terms:
|Condition:||Brand New||Brand Name:||RFJ|
|Voltage:||380V/50Hz/3P Or 220V/60||Capacity:||3tons|
|Power:||14kw||Place Of Origin:||Guangdong China|
|Ice Moulds Material:||Aliminium Plate||Ice Defrost Way:||Hot Gas Defrost|
|Cooling System:||Air Cooling With Direct Freezer||Warranty:||1 Year|
a. Ice factory
b. Fresh preservation
c. Ice engraving;
d. Edible ice
2. Block ice making machine Technical datas:
provide two kinds of block ice machine
2.1.Direct refrigeration block ice machine (adopting aluminum alloy plate to freeze ice directly, no brine tank or other auxiliary chemicals)
2.2.Brine system block ice machine
2.2.1, non containerized ice block machine
1. Daily capacity: from 1 ton to 100 tons per set/24 hours.
2. Weight of each block ice: 5kg, 10kg, 15kg, 20kg, 25kg, 30kg....50kg...100kg. We also can customize for you.
2.2.2, Containerized Ice Block Machine
1.20 feet container: 5 tons
2.40 feet container : 10 tons
3.Block ice: 10 kg, 25 kg.
3. Product advatanges and photos
1. Module design, easy to install;
2. Strong ability of keeping a low temperature;
3. Full automatic control system, low labor force costs and low maintenance costs;
4. Environmental-friendly design
50 Set/Sets per Month
Packed by in bubble film or plywood case
Lead Time :
35 days after getting down payment
Ice block making process
# Add water into the ice moulds.
# Turn on the ice block machine
# Turn off the ice block machine, ice making time different from ice weight and thickness.
# Wait minutes, ice blocks will be fully frozen with the remained coldness
# Press the ice harvest button, hot gas will into the aluminum ice moulds, ice block will be separated from the ice moulds, then we can release the ice bed, all ice blocks will drop together.
Faster ice Making /Lower power consumption
Aluminum evaporator is of 3 times higher heat exchange efficiency than other steel [SUS304, galvanized steel], so ice block can be completely frozen faster. In this way, it can produce more ice blocks with lower power consumption
Clean ice Block Making
ice block machine can make ice block directly without via brine and any other pollution, so it can produce clean ice blocks even for human consumption.
All aluminum made ice moulds
All food standard ice blocks[sanitary depends on the water quality]
Without salt and other material's corrosion, Koller all DK series ice block machine with longer service life and you need just clean the ice moulds/ice machine regularly. The fucture maintenance investment is lower.
For ice making is faster than traditional brine type ice block machine, same capacity, our DK series ice block machine takes less space than the brine type ice block machine
DK series ice block machine don't need salt water for ice block making, also it won't produce any pollution to the environment
Add water-ice making-wait-ice dropping and ice block moving away. DK series ice block machine need only your labor cost to move the ice blocks, all other process is automatically finished.
*Ice making capacity would be changed depending on installation place, refrigerator’s freezing capability, or surrounding usage environment such as outside temperature
* Please request a specification for each machine type.
*Specification will be changed without any notification.
BLOCK ICE MACHINE INSTALLATION SUGGESTION
As ice block machine should be installed indoor and air cooling type ice block machine is all in one design, to avoid the heating effect, suggest you install it in a room with good ventilation.
