Product Details:
Payment & Shipping Terms:
|
| Place Of Origin: | Jiangsu, China (Mainland) | Brand Name: | Copeland |
|---|---|---|---|
| Model Number: | ZB66KQE-TFD-551, ZB66KQE-TFD-550 | Type: | Refrigeration Compressor |
| Nominal Power: | 9HP | Refrigerant: | R404A, R507 |
| Displacement (50H: | 25.7/31.0 M3/hr | Cooling Capacity: | 16.35kW (Te=-10℃, Tc=40℃, 50Hz) |
| Connection Size: | 7/8" X 1-3/8" | Voltage: | 380-420/460V-3-50/60Hz |
| Dimensions: | 264x284x546mm | Connection Code: | 550 Brazing / 551 Rotalock |
| Weight (NW/GW): | 59/62kgs | ||
| High Light: | screw type air compressor,copeland refrigeration compressors |
||
Brand New R404A ZB ZB66KQE Copeland Scroll Compressor ZB66KQE-TFD-550
ZB66KQE-TFD-551
9HP
Refrigerant: R404/R22 50Hz
Low Temperature
2-15HP
One model for multi-refrigerants R-404A, R-407A, R-134A certain models and R-22
High tolerance to liquid slugging thanks to its axial and radial scroll compliance
Large Operating envelope and low condensing capabilities down to 10° C
Easy, efficient and reliable liquid injection with Discharge Temperature Control Valve (DTC)
Availability of Copeland Scroll Digital® Technology
| Model No. | Nom HP | Displ. cc/rev | evaporating temperature: ° c | Nom current | weight(kgs) | ||||||
| -40 | -35 | -25 | -15 | -5 | 0 | 5 | |||||
| ZF06K4E TFD550 | 2 | 34 | 900 | 1134 | 1600 | 2450 | 3300 | 3960 | 4673 | 4.3 | 26 |
| ZF08K4E TFD550 | 2.5 | 41.9 | 1100 | 1433 | 2100 | 3150 | 4200 | 5040 | 5947 | 4.6 | 29 |
| ZF09K4E TFD550 | 3 | 46.4 | 1200 | 1500 | 2300 | 3300 | 4700 | 5600 | 6600 | 5.4 | 30 |
| ZF11K4E TFD550 | 3.5 | 57.5 | 1500 | 1800 | 2800 | 4100 | 5800 | 7000 | 8300 | 6.4 | 31 |
| ZF13K4E TFD551 | 4 | 67.8 | 1700 | 2100 | 3200 | 4800 | 6900 | 8200 | 9700 | 4.6 | 39 |
| ZF15K4E TFD551 | 5 | 83.3 | 2100 | 2600 | 3900 | 5800 | 8300 | 10000 | 11800 | 5.7 | 43 |
| ZF18K4E TFD551 | 6 | 98.8 | 250 | 3100 | 4800 | 6900 | 10000 | 12000 | 14200 | 8 | 43 |
| ZF24K4ETWD551 | 7.5 | 126 | 3060 | 3800 | 580 | 8500 | 12300 | 14700 | 17400 | 12.2 | 100 |
| ZF33K4ETWD551 | 10 | 166 | 4350 | 5300 | 8200 | 12200 | 17500 | 20800 | 24500 | 17 | 102 |
| ZF40K4ETWD551 | 13 | 204 | 5200 | 6400 | 10000 | 14800 | 21300 | 25500 | 30100 | 18.4 | 108 |
| ZF48K4ETWD551 | 15 | 244 | 6000 | 7400 | 11400 | 16900 | 24500 | 29300 | 34600 | 22.5 | 113 |
| nominal capacity: r404a Watts | |||||||||||
| r404a L/m/hBp compressors 415/3 | |||||||||||
