Product Details:
Payment & Shipping Terms:
|
| Certification: | CE | Type: | Refrigerator Compressor |
|---|---|---|---|
| Warranty: | 1 Year | Color: | Black |
| Condition: | New | Refrigerant: | R404 |
| Voltage: | 50 Hz, 3 - Phase, 380/420 V. | Material: | Stainless Steel |
| High Light: | evaporator in refrigeration system,air cooler evaporator |
||
Copeland Hermetic piston compressors ZR12M3E-TWD-551 with R404A
1, Product Description:
| Power supply [V/~/Hz]: | 1 3/8" | |
| Locked rotor current [A]: | 7/8" | |
| Max. operating current [A]: | 1 1/4" | |
| Winding resistance [Ω]: | 319/357 |
Electrical data
| milimeters | inches | ||
| Suction Rotolock valve connection: | 1 3/4" | ||
| Discharge Rotolock valve connection: | 1 1/4" | ||
| Suction connection with supplied sleeve: | 1 3/8" | ||
| Discharge connection with supplied sleeve: | 7/8" |
| Nominal motor power [HP]: | 10 | |
| Displacement [m³/h]: | 28,8 | |
| Sound pressure level : | 67 | |
| Gross/Net weight [kg]: | 111/100 | |
| Oil charge [dm³]: | 4,1 |
2, product feature and application:
Features for Copeland Scroll 7–15 HP:
(1)Designed for superior R-410A efficiency and performance
(2)Features Advanced Scroll Temperature Protection (ASTP) to guard the compressor from the scroll overheating
(3)Light, compact design with smaller suction fittings for applied cost saving
(4)R-410A and R-22/R-407C models in 7–15 HP (tandems up to 30 HP)
3,Product details
| Model | Horse Power | Refrigerating Output | Input Power | Input Current | Base Size | Weight | Height | Connection |
| (HP) | (w) | (kw) | (A) | (mm) | (kg) | (mm) | (mm/Inch) | |
| ZR94KC-TFD-522 | 8 | 22940 | 7 | 16.4 | 190 | 58 | 497 | Inφ28Outφ22 |
| ZR108KC-TFD-522 | 9 | 26250 | 7.83 | 17.3 | 190 | 63 | 552 | Inφ28Outφ22 |
| ZR125KC-TFD-522 | 10 | 30470 | 9.06 | 19.2 | 190 | 63 | 552 | Inφ35Outφ22 |
| ZR144KC-TFD-522 | 12 | 34730 | 19.6 | 190 | 63 | 552 | Inφ35Outφ22 | |
| ZR9M3-TWD-551 | 7.5 | 21540 | 6.62 | 14.6 | 220 | 91 | 553 | In1 1/3" Out1" |
| ZR11M3-TWD-551 | 9 | 25840 | 7.8 | 17.8 | 220 | 91 | 553 | In1 1/3" Out1" |
| ZR12M3-TWD-551 | 10 | 29890 | 8.95 | 17.9 | 220 | 92 | 553 | In1 1/3" Out1" |
| ZR16M3-TWD-551 | 13 | 37330 | 11.17 | 25 | 220 | 98 | 553 | In1 1/3" Out1" |
| ZR19M3-TWD-522 | 15 | 45170 | 13.4 | 27.2 | 220 | 112 | 598 | Inφ42 Outφ2 |
4, Our main compressor lines are :
· compressors,
· Copeland scroll compressors: CR,VR, ZB ,ZR, ZF,ZP SERIES
· Copeland Semi-hermetic compressors: DL,D2,D4,D6,D8 SERIES
· performer compressors: SM, SZ, SH SERIES
· commercial compressors: FR, SC SERIES
· Maneurop piston compressors:MT, MTZ, NTZ, MPZ SERIES
· Secop compressor, Carrier(Carlyle) compressor
· Hitachi compressor,Daikin compressor, Sanyo compressor
·Tecumseh compressor, LG compressor, Mitsubishi compressor,
·Toshiba compressor, Panasonic compressor, Embraci Aspera compressor
