Piston Refrigeration Compressor MT160-4VM / MTZ160-4VM R22/R407C/R134a 400V/50Hz

 Piston Refrigeration Compressor MT160-4VM / MTZ160-4VM R22/R407C/R134a 400V/50Hz
 Piston Refrigeration Compressor MT160-4VM / MTZ160-4VM R22/R407C/R134a 400V/50Hz  Piston Refrigeration Compressor MT160-4VM / MTZ160-4VM R22/R407C/R134a 400V/50Hz  Piston Refrigeration Compressor MT160-4VM / MTZ160-4VM R22/R407C/R134a 400V/50Hz  Piston Refrigeration Compressor MT160-4VM / MTZ160-4VM R22/R407C/R134a 400V/50Hz

Large Image :  Piston Refrigeration Compressor MT160-4VM / MTZ160-4VM R22/R407C/R134a 400V/50Hz

Product Details:
Place of Origin: France
Brand Name: (Maneurop)
Certification: CE, ROHS
Model Number: MT160/MTZ 160
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: discussed
Packaging Details: Wooden case
Delivery Time: 7-10 working days after receiving payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5,000pcs per month
Detailed Product Description
Piston Type: Reciprocating Configuration: Stationary
Power Source: AC Power Lubrication Style: Lubricated
Gas: R22/R134a Drive Mode: Electric
Color: Blue Type: Refrigeration Piston Compressor
High Light:

screw type air compressor

,

scroll compressor refrigeration



Maneurop/ compressor MT/MTZ 160,R22/R407C/R134a,400V/50Hz



Specification:



Maneurop MT/MTZ series compressors are of the hermetic reciprocating type and are designed for Medium and high evaporating temperature applications.



There are 26 different models with displacement ranging from 30-543cm3/rev.



Our Maneurop compressors are for 50Hz, motor code is 4, can be used for R22/R407C/R134a/R404A/R507



1. Piston /reciprocating type compressors.



2. Voltage is 50Hz



3. The refrigerant are R22/R407C/R134a/R404A/R507



4. There are MT/MTZ series



5. Original from France.



6. Capacity: 1.5HP~13HP, High efficiency, Low noise



1. MT series for R134a

2. MTZ series for R407c/134a



1. 50 Hz

2. Imported form France.

3. R22 Rated condition:50Hz/400V

superheat:11.1K

subcooling 8.3K condensing temp:54.4°C



4. R407C Rated condition :50Hz 400V

superheat:11.1K

subcooling 8.3K condensing temp:54.4°C

evaporating temp.7.2°C



refrigeration and power input±5%



We can supply more compressor models as below:



MODEL (R22) MODEL (R404A) NTZ series
MT18-4VM MTZ18-4VM NTZ048A4LR1A
MT22-4VM MTZ22-4VM NTZ068A4LR1A
MT28-4VM MTZ28-4VM NTZ096A4LR1A
MT32-4VM MTZ32-4VM NTZ108A4LR1A
MT36-4VM MTZ36-4VM NTZ136A4LR1A
MT40-4VM MTZ40-4VM NTZ215A4LR1A
MT44-4VM MTZ44-4VM NTZ271A4LR1A
MT50-4VM MTZ50-4VM
MT56-4VM MTZ56-4VM
MT64-4VM MTZ64-4VM
MT72-4VM MTZ72-4VM
MT80-4VM MTZ80-4VM
MT100-4VM MTZ100-4VM
MT125-4VM MTZ125-4VM
MT144-4VM MTZ144-4VM
MT160-4VM MTZ160-4VM



Model NO. Nom HP Displ. Cc/rev Capacity R404a(w)
-10 -5
MTZ18-4VI 1.5 30.2 1580 2110
MTZ18-5VI 1.5 30.2 1580 2110
MTZ22-4VI 1.8 38.12 2270 2920
MTZ22-5VI 1.8 38.12 2270 2920
MTZ28-4VI 2.3 48.06 2880 3720
MTZ28-5VI 2.3 48.06 2880 3720
MTZ32-4VI 2.7 53.86 3230 4220
MTZ32-5VI 2.7 53.86 3230 4220
MTZ36-4VI 3 60.47 3800 4870
MTZ36-5VI 3 60.47 3800 4870
MTZ40-4VI 3.3 67.89 4280 5490
MTZ45-4VI 3.8 76.22 4420 5840
MTZ51-4VI 4.2 85.64 5290 6920
MTZ57-4VI 4.8 96.13 6060 7880
MTZ65-4VI 5.4 107.71  7080 9130
MTZ73-4VI 6.1 120.94 7960 10230
MTZ81-4VI 6.8 135.78   9160 11720
MTZ100-4VI 8.3 171.26 10390 13500
MTZ125-4VI 10.4 215.44 13650  17500
MTZ144-4VI 12 241.87 15740  20120
MTZ160-4VI 13.3 271.55 17690  22520



Code no. HP MT-R22 MTZ-R407C MTZ-R134a MTZ-R404
Kw BTUH EER Kw BTUH EER Kw BTUH EER Kw BTUH EER
MT/MTZ18 1.5 1.74 15900 9.15 1.67 15300 9.13 1.22 11200 9.2 1.76 10300 5.1
MT/MTZ22 2 2.27 22000 9.68 2.17 19600 9 1.54 14800 9.63 2.05 14100 6.01
MT/MTZ28 2.5 3.07 30200 9.86 2.83 25100 8.9 2.04 19300 9.42 2.68 18300 5.96
MT/MTZ32 2.75 3.58 33000 9.22 3.21 28400 8.86 2.39 20900 8.76 2.99 20100 5.85
MT/MTZ36 3 4.05 38000 9.38 3.75 32700 8.73 2.75 24500 8.91 3.34 23200 6.05
MT/MTZ40 3.5 4.63 42900 9.27 4.33 37400 8.64 3.08 27900 9.03 3.77 26400 6.11
MT/MTZ44 4 4.67 45200 9.69 4.37 43000 9.84 3.14 29800 9.51 4.18 27800 6.65
MT/MTZ50 4.5 5.18 50500 9.74 4.96 48100 9.71 3.6 34500 9.57 4.83 32500 6.73
MT/MTZ56 5 6.05 56400 9.32 5.67 54300 9.59 3.95 38000 9.62 5.44 36500 6.71
MT/MTZ64 5.5 6.8 64800 9.53 6.36 60400 9.5 4.68 45300 9.66 6.12 41500 6.78
MT/MTZ72 6 7.58 70100 9.26 7.22 67900 9.41 5.19 50000 9.63 6.91 46500 6.72
MT/MTZ80 7 8.56 80000 9.35 8.24 76900 9.33 6 56500 9.42 8.03 52500 6.54
MT/MTZ100 9 9.59 95900 10 9.9 94400 9.53 6.5 63900 9.84 8.72 60800 6.07
MT/MTZ125 10 12.81 124600 9.73 12.62 122100 9.67 7.72 78900 10.2 11.37 78400 6
MT/MTZ144 12 14.36 140700 9.8 14.47 137200 9.48 9.82 96900 9.87 13 92300 6.19
MT/MTZ160 13.5 16.09 156800 9.75 16.67 155100 9.31 10.92 107600 9.85 14.74 100300 5.93



 Piston Refrigeration Compressor MT160-4VM / MTZ160-4VM R22/R407C/R134a 400V/50Hz 0

 Piston Refrigeration Compressor MT160-4VM / MTZ160-4VM R22/R407C/R134a 400V/50Hz 1
