Hermetic Stationary Maneurop Piston Refrigeration Compressor NTZ068A4LR1A

Good quality Refrigeration Condensing Units for sales
Good quality Refrigeration Condensing Units for sales
We have received the Danfoss compressor purchased in July. The package is beautiful and the quality is excellent. We will cooperate with rifter in the next order.

—— Mr.Rosalind

After visiting your office and factory on August 1 this year, we are more confident to cooperate with your company. We plan to build two or three seafood cold storage warehouses in our city at the later stage. This order will be negotiated well with your business manager.

—— Benet’s Refrigeration Ltd

Your company's service is warm, especially Miss Liana. We are happy to cooperate with her this time, and the quotation is fast, the products are received soon, and the quality is good. Looking forward to cooperating with your company.

—— Mr.Mike Smith

Since 2013, I have ordered 10 refrigeration parts from your company, and then ordered the whole batch of ZB series compressor.

—— Miss April

In July, we purchased 5 Bitzer Compressor from your company and used it well. This time, we also want to buy a grain compressor.

—— Mrs Jane Smith

In may this year, we ordered a bizer water cooling unit in your company. After two months of installation, the customer reported that it was running well. We plan to continue to order five units in October.

—— Arianto Gunawan

I'm Online Chat Now

Hermetic Stationary Maneurop Piston Refrigeration Compressor NTZ068A4LR1A

China Hermetic Stationary Maneurop Piston Refrigeration Compressor NTZ068A4LR1A supplier
Hermetic Stationary Maneurop Piston Refrigeration Compressor NTZ068A4LR1A supplier Hermetic Stationary Maneurop Piston Refrigeration Compressor NTZ068A4LR1A supplier Hermetic Stationary Maneurop Piston Refrigeration Compressor NTZ068A4LR1A supplier

Large Image :  Hermetic Stationary Maneurop Piston Refrigeration Compressor NTZ068A4LR1A

Product Details:

Place of Origin: France
Brand Name: Danfoss(Maneurop)
Certification: CE, ROHS
Model Number: NTZ068A4LR1A

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: 商议
Packaging Details: Wooden case
Delivery Time: 7-10 working days after receiving payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5,000pcs per month
Contact Now
Detailed Product Description
Piston Type: Reciprocating Configuration: Stationary
Power Source: AC Power Lubrication Style: Lubricated
Gas: R134a Drive Mode: Electric
Color: Blue Type: Refrigeration Piston Compressor
Net Weight: 56KG

Maneurop Compressor NTZ068A4LR1A



Specification:



Maneurop MT/MTZ series compressors are of the hermetic reciprocating type and are designed for Medium and high evaporating temperature applications.



There are 26 different models with displacement ranging from 30-543cm3/rev.



Our Maneurop compressors are for 50Hz, motor code is 4, can be used for R22/R407C/R134a/R404A/R507



1. Piston /reciprocating type compressors.



2. Voltage is 50Hz



3. The refrigerant are R22/R407C/R134a/R404A/R507



4. There are MT/MTZ series



5. Original from France.



6.Capacity: 1.5HP~13HP, High efficiency, Low noise



1.MT series for R134a

2. MTZ series for R407c/134a



1.50 Hz

2. Imported form France.

3.R22 Rated condition:50Hz/400V

superheat:11.1K

subcooling 8.3K condensing temp:54.4°C



4.R407C Rated condition :50Hz 400V

superheat:11.1K

subcooling 8.3K condensing temp:54.4°C

evaporating temp.7.2°C



refrigeration and power input±5%



We can supply more Danfoss compressor models as below:



MODEL (R22) MODEL (R404A) NTZ series
MT18-4VM MTZ18-4VM NTZ048A4LR1A
MT22-4VM MTZ22-4VM NTZ068A4LR1A
MT28-4VM MTZ28-4VM NTZ096A4LR1A
MT32-4VM MTZ32-4VM NTZ108A4LR1A
MT36-4VM MTZ36-4VM NTZ136A4LR1A
MT40-4VM MTZ40-4VM NTZ215A4LR1A
MT44-4VM MTZ44-4VM NTZ271A4LR1A
MT50-4VM MTZ50-4VM
MT56-4VM MTZ56-4VM
MT64-4VM MTZ64-4VM
MT72-4VM MTZ72-4VM
MT80-4VM MTZ80-4VM
MT100-4VM MTZ100-4VM
MT125-4VM MTZ125-4VM
MT144-4VM MTZ144-4VM
MT160-4VM MTZ160-4VM



Model NO. Nom HP Displ. Cc/rev Capacity R404a(w)
-10 -5
MTZ18-4VI 1.5 30.2 1580 2110
MTZ18-5VI 1.5 30.2 1580 2110
MTZ22-4VI 1.8 38.12 2270 2920
MTZ22-5VI 1.8 38.12 2270 2920
MTZ28-4VI 2.3 48.06 2880 3720
MTZ28-5VI 2.3 48.06 2880 3720
MTZ32-4VI 2.7 53.86 3230 4220
MTZ32-5VI 2.7 53.86 3230 4220
MTZ36-4VI 3 60.47 3800 4870
MTZ36-5VI 3 60.47 3800 4870
MTZ40-4VI 3.3 67.89 4280 5490
MTZ45-4VI 3.8 76.22 4420 5840
MTZ51-4VI 4.2 85.64 5290 6920
MTZ57-4VI 4.8 96.13 6060 7880
MTZ65-4VI 5.4 107.71  7080 9130
MTZ73-4VI 6.1 120.94 7960 10230
MTZ81-4VI 6.8 135.78   9160 11720
MTZ100-4VI 8.3 171.26 10390 13500
MTZ125-4VI 10.4 215.44 13650  17500
MTZ144-4VI 12 241.87 15740  20120
MTZ160-4VI 13.3 271.55 17690  22520



Code no. HP MT-R22 MTZ-R407C MTZ-R134a MTZ-R404
Kw BTUH EER Kw BTUH EER Kw BTUH EER Kw BTUH EER
MT/MTZ18 1.5 1.74 15900 9.15 1.67 15300 9.13 1.22 11200 9.2 1.76 10300 5.1
MT/MTZ22 2 2.27 22000 9.68 2.17 19600 9 1.54 14800 9.63 2.05 14100 6.01
MT/MTZ28 2.5 3.07 30200 9.86 2.83 25100 8.9 2.04 19300 9.42 2.68 18300 5.96
MT/MTZ32 2.75 3.58 33000 9.22 3.21 28400 8.86 2.39 20900 8.76 2.99 20100 5.85
MT/MTZ36 3 4.05 38000 9.38 3.75 32700 8.73 2.75 24500 8.91 3.34 23200 6.05
MT/MTZ40 3.5 4.63 42900 9.27 4.33 37400 8.64 3.08 27900 9.03 3.77 26400 6.11
MT/MTZ44 4 4.67 45200 9.69 4.37 43000 9.84 3.14 29800 9.51 4.18 27800 6.65
MT/MTZ50 4.5 5.18 50500 9.74 4.96 48100 9.71 3.6 34500 9.57 4.83 32500 6.73
MT/MTZ56 5 6.05 56400 9.32 5.67 54300 9.59 3.95 38000 9.62 5.44 36500 6.71
MT/MTZ64 5.5 6.8 64800 9.53 6.36 60400 9.5 4.68 45300 9.66 6.12 41500 6.78
MT/MTZ72 6 7.58 70100 9.26 7.22 67900 9.41 5.19 50000 9.63 6.91 46500 6.72
MT/MTZ80 7 8.56 80000 9.35 8.24 76900 9.33 6 56500 9.42 8.03 52500 6.54
MT/MTZ100 9 9.59 95900 10 9.9 94400 9.53 6.5 63900 9.84 8.72 60800 6.07
MT/MTZ125 10 12.81 124600 9.73 12.62 122100 9.67 7.72 78900 10.2 11.37 78400 6
MT/MTZ144 12 14.36 140700 9.8 14.47 137200 9.48 9.82 96900 9.87 13 92300 6.19
MT/MTZ160 13.5 16.09 156800 9.75 16.67 155100 9.31 10.92 107600 9.85 14.74 100300 5.93





Hermetic Stationary Maneurop Piston Refrigeration Compressor NTZ068A4LR1A
