15000W 49800BTU Refrigeration Scroll Compressor JT160GABY1L 5HP 380V/3PH/50HZ 49800BTU

15000W 49800BTU Refrigeration Scroll Compressor JT160GABY1L 5HP  380V/3PH/50HZ 49800BTU
15000W 49800BTU Refrigeration Scroll Compressor JT160GABY1L 5HP  380V/3PH/50HZ 49800BTU 15000W 49800BTU Refrigeration Scroll Compressor JT160GABY1L 5HP  380V/3PH/50HZ 49800BTU 15000W 49800BTU Refrigeration Scroll Compressor JT160GABY1L 5HP  380V/3PH/50HZ 49800BTU 15000W 49800BTU Refrigeration Scroll Compressor JT160GABY1L 5HP  380V/3PH/50HZ 49800BTU

Large Image :  15000W 49800BTU Refrigeration Scroll Compressor JT160GABY1L 5HP 380V/3PH/50HZ 49800BTU

Product Details:
Place of Origin: China
Brand Name: Daikin
Certification: CE SGS
Model Number: JT160GABY1L
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: discussed
Packaging Details: wooden case/pallet
Delivery Time: 3-7 days
Payment Terms: T/T
Detailed Product Description
Type: Scroll Configuration: Stationary
Power Source: AC Power Voltage: 380V/3PH/50HZ
Cooling Capactiry: 49800BTU Hp: 5hp
Refrigerant: R22
High Light:

screw type air compressor

,

copeland refrigeration compressors

380V 50hz 3PH Daikin air conditionary Scroll Compressor R22 JT160GABY1L 5P for cold cold storage use

Specifications

1. Model: JT160GABY1L



2. 4HP,380V/50HZ/3PH


3. Working R22 refrigerant


4. 15000W


5. COP:3.4



6. Technical Sheet



 Daikin Scroll Compressor:



Ref Power Source Model Output Performance
(HP) Testing Power  Nominal Capacity Input Current COP
  Source (KW)         (BTU/H) (KW) (A) (w/w)
R22 JT90GABV1L 3hp 220V/50Hz 8.41 28710 2.56 11.9 3.3
220V/50Hz JT95GABV1L 3hp 220V/50Hz 9.07 30960 2.75 12.8 3.3
  JT100GABV1L 3hp 220V/50Hz 9.33 31850 2.83 13.2 3.3
JT90GABY1L 3hp 380V/50Hz 8.41 28710 2.47 4.36 3.4
380V/50Hz JT95GABY1L 3hp 380V/50Hz 9.07 30960 2.67 4.62 3.4
  JT125GABY1L 4hp 380V/50Hz 11.7 39940 3.44 6 3.4
  JT160GABY1L 5hp 380V/50Hz 14.6 49830 4.3 7.5 3.4
  JT170GABY1L 5hp 380V/50Hz 15.6 53250 4.59 8.1 3.4
JT125GA-Y1 4hp 380V/50Hz 11.7 39940 3.44 6 3.4
380~415V JT160GA-Y1 5hp 380V/50Hz 14.6 49830 4.3 7.5 3.4
50Hz JT170GA-Y1 5hp 380V/50Hz 15.6 53250 4.59 8 3.4



1) High Efficiency
We provide high efficiency compressors by greater accurate maching, particular assembling and oil seal technology




2) Low Sound Levels
Using un-contact scroll, we have accomplished low sound power levels and low vibration




3) High Reliability, long operating life
DAIKIN compressor have fewer moving parts than others, low reiteration impulsion and low sliding velocity




4) Wide operating voltage range
DAIKIN compressor guaranteed within voltage range 10%




5) Special value
Due to simplifying system design and saving cost, it would enhance your product competitive in the market to us DAIKIN compressor





6) Certification: CE





7) Cooling capacity: 3hp, 3. 5hp, 4hp, 4. 5hp, 5hp, 6hp




8) Refrigerant: R22. R407c. R410a




9) Power: 220v-240v / 50hz, 380v-420v / 50hz, 380v-420v / 60hz




10) High ambient: 65 degree



Series Phase Model No. Rated Power
HP
Displacement
CC/rev
Cooling Capacity
W
input power
W
COP Foot form
BC 3ph JT90BC-Y1L 3 48.6 8540 2750 3.11 3
JT90BCBY1L 3 48.6 8540 2750 3.11 4
JT90BCCY1L 3 48.6 8540 2750 3.11 Special
JT95BC-Y1L 3 51.2 9020 2890 3.12 3
JT95BCBY1L 3 51.2 9020 2890 3.12 4
JT95BCCY1L 3 51.2 9020 2890 3.12 Special
JT125BC-Y1L 4 67 11900 3800 3.13 3
JT125BCBY1L 4 67 11900 3800 3.13 4
JT160BC-Y1L 5 83.1 15000 4660 3.22 3
JT160BCBY1L 5 83.1 15000 4660 3.22 4
JT90BC-V1L 3 48.6 8540 2890 2.96 3
JT90BCBV1L 3 48.6 8540 2890 2.96 4
JT90BCCV1L 3 48.6 8540 2890 2.96 Special
JT95BC-V1L 3 51.2 9030 3040 2.97 3
JT95BCBV1L 3 51.2 9030 3040 2.97 4
JT95BCCV1L 3 51.2 9030 3040 2.97 Special
BH 3ph JT90BH-Y1L 3 48.6 8550 2600 3.29 3
JT90BHBY1L 3 48.6 8550 2600 3.29 4
JT95BH-Y1L 3 50.8 9020 2740 3.29 3
JT95BHBY1L 3 50.8 9020 2740 3.29 4
JT90BH-V1L 3 48.6 8550 2630 3.25 3
JT90BHBV1L 3 48.6 8550 2630 3.25 4
JT90BHCV1L 3 48.6 8550 2630 3.25 Special
JT95BH-V1L 3 50.8 9020 2780 3.24 3
JT95BHBV1L 3 50.8 9020 2780 3.24 4
JT95BHCV1L 3 50.8 9020 2780 3.24 Special





15000W 49800BTU Refrigeration Scroll Compressor JT160GABY1L 5HP  380V/3PH/50HZ 49800BTU 0
