DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR

China DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR supplier
DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR supplier DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR supplier DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR supplier DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR supplier

Large Image :  DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR

Product Details:

Place of Origin: Japan
Brand Name: DAIKIN
Certification: CE, ROHS
Model Number: JT1G-VDK1YR

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: 商议
Packaging Details: Wooden case
Delivery Time: 7-10 working days after receiving payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5,000pcs per month
Contact Now
Detailed Product Description
Piston Type: Rotary Configuration: Stationary
Power Source: AC Power Lubrication Style: Lubricated
Drive Mode: Electric Type: Refrigeration Piston Compressor
Temperature: Middle/High Horse Power: 5HP
Voltage: 380-440V/50Hz Refrigerant: R410A
Size: 450*1500*1500mm Colour: Black
Weight: 60kg



DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR



JT1G-VDL daikin scroll air compressor

power source: 380-415v,50Hz      400-440v,60Hz

 current:8.9A

 cop: 4.2W/W

 displacement:56cm3/r

 output:5 Hp



Daikin compressor Product Description



Performance Features

1) High Efficiency

We provide high efficiency compressors by greater accurate maching, particular assembling and oil seal technology

2) Low Sound Levels

Using un-contact scroll, we have accomplished low sound power levels and low vibration

3) High Reliability, long operating life

DAIKIN compressor have fewer moving parts than others, low reiteration impulsion and low sliding velocity

4) Wide operating voltage range

DAIKIN compressor guaranteed within voltage range 10%

5) Special value

Due to simplifying system design and saving cost, it would enhance your product competitive in the market to us DAIKIN compressor

6) Cooling capacity: 3hp, 3.5hp, 4hp, 4.5hp, 5hp, 6hp

7) Refrigerant: R22. R407c. R410a

8) Power: 220v-240v / 50hz, 380v-420v / 50hz, 380v-420v / 60hz

9) High ambient: 65 degree

10) Packing: 24pc / pallet


We can supply more Danfoss compressor models as below:





MODEL

OUTPUT

(HP)

POWER

SOURCE

(V/Hz)


PERFORMANCE

TUBE CONNECTIONS

NETWEIGHT
INCLUDING 0IL
(Kg)

NOMINAL

CAPACITY

(W)

INPUT

(kW)

(W/W)

dB(A)

SUCTION TUBE
mm

DISCHARGE TUBE

mm

JT90GABY1L

3

380/50

8410

2.47

3.4

61

φ 22.1

φ 16

29.0

JT95GABY1L

3

380/50

9070

2.67

3.4

61

φ 22.1

φ 16

29.0

JT125GABY1L

4

380/50

11700

3.44

3.4

63

φ 22.1

φ 16

31.6

JT160GABY1L

5

380/50

14600

4.30

3.4

63

φ 22.1

φ 16

32.2

JT170GABY1L

5

380/50

15600

4.59

3.4

63

φ 22.1

φ 16

33.1





daikin compressor
Model Output (HP) Power Source (V/Hz) Performance

Nominal

Capacity (W)

Input Power (Kw) COP (W/W) Noise (dB)
JT90BCB-V1L 3 220/50 8540 2.89 2.96 58
JT90BC-Y1L 3 380/50 8540 2.75 3.11 58
JT95BCB-Y1L 3 380/50 8540 2.75 3.11 58
JT95BC-Y1L 3 380/50 9030 2.89 3.12 58
JT125BC-Y1L 4 380/50 11900 3.8 3.13 60
380/60 14200 4.53 3.13 63
JT125BCB-Y1L 4 380/50 11900 3.8 3.13 60
380/60 14200 4.53 3.13 63
JT160BC-Y1L 5 380/50 15000 4.66 3.22 60
380/60 17900 5.53 3.23 63
JT160BCB-Y1L 5 380/50 15000 4.66 3.22 60
380/60 17900 5.53 3.23 63
JT212D-Y1L 7.5 380/50 21500 6.49 3.31 72
JT212D-YE 400/60 25100 7.66 3.28 75
JT236D-Y1L 7.5 380/50 24000 7.2 3.33 72
JT236D-YE 400/60 28300 8.53 3.32 75
JT265D-Y1L 8 380/50 26700 7.95 3.36 72
JT265D-YE 400/60 31800 9.45 3.37 75
JT300D-Y1L 10 380/50 29900 8.85 3.38 72
JT300D-YE 400/60 35200 10.4 3.38 75
JT315D-Y1L 11 380/50 31100 9.15 3.4 72
JT335D-Y1L 12 380/50 34000 9.98 3.41 72
JT335D-YE

400/60

40100 11.8 3.4 75



DAIKIN Rotary Freezer Piston Refrigeration Compressor JT1G - VDK1YR
