Black Dixell Thermostatic Controller, Pengatur Suhu Digital Dual output termostat XT120C
refrigerator temperature control
,Carel Suhu Controller
Deskripsi Produk:
1.Shell: ABS sublight flame retardant plastic;
2.Dimensi: depan 32x74 mm; Deep 60 mm
3.Mounting dimensi: tetap di lubang terbuka untuk panel 71x29mm;
4.Overall tingkat perlindungan: IP20; Tingkat perlindungan panel depan: IP65;
5.Connecting terminal: tekanan baut, diameter kawat kurang dari 2.5mm2
6.Power supply: 230Vac + 10%, 50 / 60hz
7.Power konsumsi: maksimum 3VA;
8. Tampilan: 3 tabung digital merah, tinggi 14,2 mm;
9.Input: 2 saluran input NTC atau PTC atau PT100 atau TC-J atau TC-K
10.Output relay: kompresor / plus hotline: 20 (8) 250Vac
11.Data penyimpanan: elektrik dihapus memori menulis elektronik (EEPROM).
12Kontrol tingkat: 1B; Tingkat lingkungan: 2; Tingkat perangkat lunak: A;
13.Maximum insulation voltage: 2500V; Grade dari tegangan lebih: II;
14.Working temperature: 0 ~ 60 ° C; Suhu penyimpanan: - 30 ~ 85 ° C.
15. Kelembaban luar: 20 ~ 85RH% (tidak terpajan)
16.Measure and control range temperatur: NTC: - 40 ~ 110 ° C; PTC: - 50 ~ 150 ° C; PT100: 60-200 - plus; TC - J: 0 sampai + 600 ℃, K: 0 sampai + 999 ℃
17.Resolusi: 0,1 ° C atau 1 ° C; Presisi (pada suhu sekitar 25 ° C), ditambah atau minus 1 ° C + 1
Lebih banyak model seperti di bawah ini:
| XR01CX-5N0C1 | XR02CX |
| XR03CX-5N0C0 | XR03CX |
| XR04CX-5N0C1 | XR04CX |
| XR06CX-5N0C1 | XR06CX |
| XR10CX-5N0C1 | XR10CX |
| XR30CX-5N0C1 | XR30CX |
| XR40CX-5N0C1 | XR40CX |
| XR60CX-5N0C1 | XR60CX |
| XR30CX-5R0C1 | XR20CX |
| XR60CX-5R0C1 |
