| Model Number: | 8FC-70.2Y-40P |
| MOQ: | 1pcs |
| Price: | discussed |
| Delivery Time: | 7-10 working days after receiving payment |
| Payment Terms: | L/C,T/T,Western Union |
High efficiency 70 HP piston compressor designed for commercial refrigeration applications. Model 8FC-70.2Y-40P delivers reliable performance with advanced engineering features.
Model: 8FC-70.2(Y)
Voltage: 380V-420V/50Hz, 440-460V
Refrigerant Gas: R22 or R134a, R404
Cylinders: 8
Horsepower: 70 HP
The compressor uses R22 as primary refrigerant, with compatibility for R134a, R404a, R407b, and R407c. Suitable for both low and high condensing temperature applications. R12 and R502 are not recommended due to environmental protection requirements.
Features scientific structural design, precision materials, and strict manufacturing processes. Factory holds National Compulsory Products CCC Certification, National Industrial Products Manufacture License, and ISO9001:2008 International Quality Supervision System Certification.
| Model | Horse Power | Displacement (50Hz) m³/h | Cylinder Configuration (Qty*Diameter*Stroke mm) |
|---|---|---|---|
| 2DC-2.2 | 2 | 13.5 | 2*50*39.3 |
| 2DC-3.2 | 3 | 13.5 | 2*50*39.3 |
| 2CC-3.2 | 3 | 16.2 | 2*55*39.3 |
| 2CC-4.2 | 4 | 16.2 | 2*55*39.3 |
| 4DC-5.2 | 5 | 26.84 | 4*50*39.3 |
| 4DC-7.2 | 7 | 26.84 | 4*50*39.3 |
| 4CC-6.2 | 6 | 32.48 | 4*55*39.3 |
| 4CC-9.2 | 9 | 32.48 | 4*55*39.3 |
| 4TCS-8.2 | 8 | 41.33 | 4*60*42 |
| 4TCS-12.2 | 12 | 41.33 | 4*60*42 |
| 4PCS-10.2 | 10 | 48.5 | 4*65*42 |
| 4PCS-15.2 | 15 | 48.5 | 4*65*42 |
| 4NCS-12.2 | 12 | 56.25 | 4*70*42 |
| 4NCS-20.2 | 20 | 56.25 | 4*70*42 |
| 4H-15.2 | 15 | 73.6 | 4*70*55 |
| 4H-25.2 | 25 | 73.6 | 4*70*55 |
| 4G-20.2 | 20 | 84.5 | 4*75*55 |
| 4G-30.2 | 30 | 84.5 | 4*75*55 |
| 6H-25.2 | 25 | 110.5 | 6*70*55 |
| 6H-35.2 | 35 | 110.5 | 6*70*55 |
| 6G-30.2 | 30 | 126.8 | 6*75*55 |
| 6G-40.2 | 40 | 126.8 | 6*75*55 |
| 6F-40.2 | 40 | 151.6 | 6*82*55 |
| 6F-50.2 | 50 | 151.6 | 6*82*55 |
| S6H-20.2 | 20 | 36.8 | 6*70*55 |
| S6G-25.2 | 25 | 42.3 | 6*75*55 |
| S6F-30.2 | 30 | 50.5 | 6*82*55 |
| Model | Cond Temp | Evaporation Temperature Performance Data |
|---|---|---|
| 8FC-70.2Y | 40 | 223000 | 204900 | 172100 | 143500 | 118400 | 96500 | 77400 |
Complete performance data available for all models upon request.
|
|
