BOX Side Discharge Type Refrigeration Unit Kondensasi untuk Semi - Hermetik
ac condenser unit
,air cooled condensing unit
Unit seri AXX dirancang khusus untuk memenuhi permintaan pasar. Kami mengadopsi tabung aluminium penukar panas tembaga dengan efisiensi tinggi, dengan aksesoris pendingin premium. Ini sangat kompak dalam struktur. Desainnya bergaya design.elegant, dalam masa kerja yang panjang, mudah dipasang. Ini banyak digunakan untuk peralatan pendingin untuk cold storage dan food showcase.
| model | kondensator | Persediaan poer | Motor kipas | Spesifikasi tabung penghubung | ||||||
| model | Daya nominal (HP) | Kapasitas pendinginan (W) | 380V 3PH 50HZ | Dia dari kipas angin (mm) | Volume (m3 / h) | Kekuasaan (w) | Returngas (mm) | Outlet (mm) | ||
| AX-XQ02HZ | ZB15KQ | 2HP | 5500 | 420 | 3200 | 60 | 16 | 10 | ||
| AX-XQ03HZ | ZB21KQ | 3HP | 7900 | 450 | 5800 | 60 | 16 | 10 | ||
| AX-XQ04HZ | ZB29KQ | 4HP | 10620 | 450 | 2 * 5800 | 2 * 60 | 22 | 12 | ||
| AX-XQ05HZ | ZB38KQ | 5HP | 13100 | 450 | 2 * 5800 | 2 * 60 | 22 | 12 | ||
| AX-XQ06HZ | ZB45KQ | 6HP | 1600 | 450 | 2 * 5800 | 2 * 60 | 22 | 16 | ||
| model | Dimensi (mm) | Instalasi sizze (mm) | Instalasi membosankan | |||||||
| Panjang (L) | Lebar (P) | Tinggi (H) | Panjang (A) | Lebar (B) | ||||||
| AX-XQ02HZ | 860 | 310 | 650 | 630 | 350 | Φ13 | ||||
| AX-XQ03HZ | 950 | 340 | 850 | 625 | 380 | Φ13 | ||||
| AX-XQ04HZ | 950 | 340 | 1260 | 625 | 380 | Φ13 | ||||
| AX-XQ05HZ | 950 | 340 | 1260 | 625 | 380 | Φ13 | ||||
| AX-XQ06HZ | 950 | 340 | 1260 | 625 | 380 | Φ13 | ||||
Unit Kondensasi Kompresor Tipe Kotak Pelepasan Samping ZB38KQ-TFD-558 ZB38KQE-TFD-558
Side Discharge BOX Type Compressor Condensing Unit ZB38KQ-TFD-558 ZB38KQE-TFD-558 Unit Dimensions AXX Outdoor-Box Type Compressor Condensing Unit Dimensions (mm) Model Length (L) Width (P) Height (H) AX-XQ02HZ 860 310 650 AX-XQ03HZ 950 340 850 AX-XQ04HZ 950 340 1260 AX-XQ05HZ 950 340 1260 AX-XQ06HZ ...
Unit Kondensasi Tipe BOX ZB15KQ-TFD-558 ZB15KQE-TFD-558 untuk peralatan pendingin dan lemari pajangan makanan
BOX Type Condensing Unit ZB15KQ-TFD-558 ZB15KQE-TFD-558 The AXX series BOX Type Compressor Condensing Unit is specially designed to meet market demands. Featuring high-efficiency copper tube aluminum heat exchangers and premium refrigeration accessories, this unit offers compact structure, original ...
Unit kondensasi kompresor hermetik Maneurop MT100HS4EVE MT125HU4DVE MT160HW4EVE
Maneurop Hermetic Compressor Condensing Unit MT100HS4EVE MT125HU4DVE MT160HW4EVE Product Overview Maneurop Hermetic Compressor Condensing Unit equipped with high-quality compressors from leading brands including Maneurope. Key Features Air cooled compressor condensing refrigeration equipment Premium ...
Unit Kondensasi Kompresor Hermetik Maneurop Suhu Sedang dan Rendah MT80HP4CVE MTZ80HP4CVE MTZ64HM4CVE
Medium And Low Temperature Maneurop Hermetic Compressor Condensing Unit MT80HP4CVE MTZ80HP4CVE MTZ64HM4CVE Maneurop Hermetic Compressor Condensing Unit The MG series compressor condensing unit consists of France-built Maneurop MT and LT series hermetic compressors, premium condenser, motor, base ...
