| Model Number: | ZB26KQE-TFD-522 |
| MOQ: | 1 piece |
| Price: | discussed |
| Delivery Time: | 7-10 working days after receiving payment |
| Payment Terms: | T/T, Western Union |
Black Scroll Compressor 3.5HP ZB26KQE-TFD-522 For Freezer / Cold Room
Product description:
1. scroll compressor model: 2HP-30HP
2. scroll compressor has high processing precision requirements, but has many advantages, small size, light weight, high efficiency, low vibration and high reliability.
3. scroll compressors will largely replace traditional piston compressors, which have been widely used in developed countries.
Features:
1. The (ZB series) compressor adopts a double-flex design to ensure the seal between the scrolls. The ZB series compressor allows the scroll to be separated radially and axially, and debris or liquid can pass through the scroll without damaging the compressor.
2. ZB series compressors have higher life and reliability, better liquid tolerance and better impurity tolerance.
3. compressor (ZB series) has a lower noise and vibration level smooth sound spectrum and soft sound quality.
4. The compression chamber of ZB series compressor is always symmetrically distributed, with low unbalanced stress and no vibration absorbing device.
5. ZB series compressor adopts unloading start technology. After the stop, the compression components separate the pressure balance inside the compressor from each other without additional starting device.
| Model NO. | Cindensate Temperature | The Evaporation Temperature ° C (R22/50HZ) | |||||
| -12 | -10 | -5 | 0 | 5 | 10 | ||
| ZB15KQ | 40 | 3300 | 3550 | 4350 | 5200 | 6250 | 7400 |
| ZB19KQ | 40 | 3650 | 3950 | 4850 | 5850 | 7000 | 8300 |
| ZB21KQ | 40 | 4650 | 5050 | 6200 | 7450 | 8850 | 10500 |
| ZB26KQ | 40 | 5100 | 5500 | 6800 | 8200 | 9850 | 11700 |
| ZB29KQ | 40 | 6230 | 6790 | 8290 | 9970 | 11800 | 14070 |
| ZB38KQ | 40 | 7300 | 8000 | 9950 | 12200 | 14650 | 17300 |
| ZB45KQ | 40 | 9400 | 10200 | 12400 | 14900 | 17800 | 21000 |
| ZB48KQ | 40 | 10390 | 11285 | 13700 | 16436 | 19574 | 23199 |
| ZB58KQ | 40 | 11800 | 12950 | 16100 | 19600 | 19574 | 28000 |
| ZB66KQ | 40 | 13950 | 15100 | 18400 | 22200 | 26500 | 31500 |
| ZB76KQ | 40 | 16400 | 17800 | 21700 | 28500 | 30500 | 35500 |
| ZB88KQ | 40 | 18800 | 20400 | 24900 | 30000 | 36000 | 42000 |
| ZB95KQ | 40 | 19500 | 21400 | 26500 | 32000 | 38200 | 45200 |
| ZB114KQ | 40 | 23200 | 25500 | 31700 | 38500 | 41600 | 54500 |
| Model NO. | Cindensate Temperature | The Evaporation Temperature ° C (R404/50HZ) | ||||||
| -25 | -20 | -15 | -10 | -5 | 0 | 5 | ||
| ZB15KQE | 40 | 1870 | 2430 | 3000 | 3700 | 4450 | 5350 | 6350 |
| ZB19KQE | 40 | 2490 | 3050 | 3750 | 4550 | 5450 | 6500 | 7700 |
| ZB21KQE | 40 | 3000 | 3700 | 4550 | 5000 | 6600 | 7900 | 9350 |
| ZB26KQE | 40 | 3500 | 4300 | 5250 | 6350 | 7650 | 9100 | 10800 |
| ZB29KQE | 40 | 4070 | 5040 | 6160 | 7460 | 8960 | 10680 | 12650 |
| ZB38KQE | 40 | 5100 | 6250 | 7700 | 9300 | 11200 | 13350 | 15800 |
| ZB45KQE | 40 | 6000 | 7400 | 9050 | 10950 | 13150 | 15700 | 18600 |
| ZB48KQE | 40 | 6579 | 8150 | 9969 | 12074 | 14500 | 17287 | 20471 |
| ZB58KQE | 40 | 7050 | 9250 | 11700 | 14400 | 17500 | 21000 | 24900 |
| ZB66KQE | 40 | 8900 | 11100 | 13500 | 16400 | 19600 | 23400 | 27600 |
| ZB76KQE | 40 | 10900 | 13300 | 16100 | 19400 | 23300 | 27800 | 33000 |
|
|
