| Model Number: | 4H-15.2Y-40P,4HE-18Y-40P |
| MOQ: | 1 piece |
| Price: | US$(700-1200)/PC |
| Delivery Time: | 5-7 Days |
| Payment Terms: | T/T,Western Union,MoneyGram |
| Specification | SI | IP |
|---|---|---|
| Displacement (1450 RPM 50 HZ) | 73.7 m³/h | 2599.2 CFH |
| Displacement (1750 RPM 60 HZ) | 88.83 m³/h | 3137.0 CFH |
| No. of cylinder * bore * stroke | 4*70mm*55mm | 4*2.76inch*2.17inch |
| Weight | 183 kg | 404 lb |
| Max pressure (LP/HP) | 19/32 bar | 275/464 psi |
| Connection suction line | 42mm-1 5/8" | 42mm-1 5/8" |
| Connection discharge line | 28mm-1 1/8" | 28mm-1 1/8" |
| Motor version | 2 | 2 |
| Starting current (Rotor locked) | 97.0 A Y/158.0 A YY | 176.0 A |
| Motor voltage (more on request) | 380-420V Y-3-50 HZ | 440-480V Y-3-60 HZ UL |
| Max operating current | 36.7 A | 36.7 A |
|
|
| Model Number: | 4H-15.2Y-40P,4HE-18Y-40P |
| MOQ: | 1 piece |
| Price: | US$(700-1200)/PC |
| Packaging Details: | Standard Wooden Package |
| Payment Terms: | T/T,Western Union,MoneyGram |
| Specification | SI | IP |
|---|---|---|
| Displacement (1450 RPM 50 HZ) | 73.7 m³/h | 2599.2 CFH |
| Displacement (1750 RPM 60 HZ) | 88.83 m³/h | 3137.0 CFH |
| No. of cylinder * bore * stroke | 4*70mm*55mm | 4*2.76inch*2.17inch |
| Weight | 183 kg | 404 lb |
| Max pressure (LP/HP) | 19/32 bar | 275/464 psi |
| Connection suction line | 42mm-1 5/8" | 42mm-1 5/8" |
| Connection discharge line | 28mm-1 1/8" | 28mm-1 1/8" |
| Motor version | 2 | 2 |
| Starting current (Rotor locked) | 97.0 A Y/158.0 A YY | 176.0 A |
| Motor voltage (more on request) | 380-420V Y-3-50 HZ | 440-480V Y-3-60 HZ UL |
| Max operating current | 36.7 A | 36.7 A |
