| Brand Name: | Dorin |
| Model Number: | HEX-EM 150-43 |
| MOQ: | 1 |
| Delivery Time: | 5-8 days |
| Payment Terms: | T/T,Western Union |
Product Paramenters
|
No. cylinders |
4 | |
| Bore | 59 | [mm] |
| Stroke | 45 | [mm] |
| Displacement @ 50 Hz | 42,81 | [m³/h] |
| Displacement @ 60 Hz | 51,38 | [m³/h] |
| Suction valve | 35 s. | [mm] |
| Discharge valve | 28 s. | [mm] |
| Oil charge | 2,5 | [L] |
| Net weight | 130 | [kg] |
A - Oil sight glass
B - Oil charge plug
C - Low pressure connection
D - High pressure connection
E - Oil drain plug
F - Crankcase heater
G - Oil return plug
M - Max. discharge temperature sensor
DL - Discharge service valve
SL - Suction service valve
Feature
Good seal reduces the load.
Long lifespan, no need to check or replace during maintenance.
Strong thrust bearing design.
Suitable for all standard voltages.
Small leak gap.
Fewer parts - less chance of breakage and downtime.
Company Information
Shenzhen Ruifujie Technology Co., Ltd. specializes in producing and exporting compressors,condensing unit, ice block machine ,spare parts,air-cooler,cold room,etc...for more than 20 years.The brands we supply are Copeland,Danfoss, Bitzer,Carrier,Tecumseh, Hanbell, Hitachi, Daikin, GMCC, LG...
The company has achieved breakthrough development in after-sales service, design, installation, maintenance and technical consulting, and has established long-term close cooperation with many countries around the world.
Based on the tenet of “Devotion, Integrity, Innovation, Dedication”, We will continue to provide Highest quality products for new and old customers.
.FAQ
Q:What is the packaging and shipping method?
A:By Sea: Export wooden package,with refrigerant oil.
By Air: Full-sealed wooden package, without refrigerant oil.
Q:Which port does you ship from?
A:Guangzhou/Shenzhen.
Q: What's your MOQ?
A: If we have the products in stock, it will be no MOQ. If we need to produce,
we can discuss the MOQ according to customer's exact situation.
Q: What is your term of payment?
A: 30% down payment before producing and 70% balance payment before shipping.
Q:What is the term of payment?
A:T/T, Western Union.
|
|
