| Brand Name: | Ruifujie |
| Model Number: | FNH2-80 |
| MOQ: | 1 |
| Price: | Discussed |
| Delivery Time: | 1 Month |
| Payment Terms: | T/T,Western Union |
The FNH2-80 central air condenser is engineered for large-scale central air conditioning mainframes, commercial chiller systems, and multi-compressor condensing racks. Delivering a high-capacity heat rejection rating of 26.4 kW across an 80 m² heat exchange surface, this heavy-duty unit efficiently handles peak cooling demands, ensuring continuous thermal stability across commercial and industrial facilities.
In high ambient summer environments, insufficient heat dissipation causes head pressure spikes, compressor overload, and unexpected system shutoffs. To resolve these operational challenges, this high-performance central air condenser utilizes twin 450mm axial fans driven by 2×250W motors, producing a massive 2×4800 m³/h airflow. Backed by factory 3.0 MPa pneumatic tightness testing, it guarantees long-term pressure stability and zero refrigerant leakage.
Featuring seamless inner-grooved copper tubes mechanically expanded into corrugated aluminum fins in a 5×16 circuit arrangement, this durable central air condenser maximizes heat transfer efficiency while maintaining low air resistance. Equipped with 25mm intake and 22mm liquid outlet pipe connections and an anti-corrosive powder-coated outer casing, it stands up to harsh outdoor operating conditions.
| Parameter | Value |
|---|---|
| Model | FNH2-80 |
| Heat Exchange Capacity | 26.4 kW |
| Ring Number | 5x16 |
| Heat Exchange Area | 80 m² |
| Fan Power | 2×250 W |
| Air Volume | 2×4800 m³/h |
| Intake Inlet / Liquid Outlet | 25 / 22mm |
Ruifujie brings over 20 years of manufacturing expertise to the global HVAC and refrigeration industries. The enterprise specializes in scroll, piston, rotary, semi-hermetic, and screw compressor lines, alongside integrated cold storage, blast freezer, and commercial ice equipment. Supporting full OEM/ODM customization, Ruifujie exports to key international markets across the US, UK, UAE, and Saudi Arabia, winning global customer trust through reliable engineering and competitive cost performance.
Leveraging more than two decades of HVAC and refrigeration expertise, Ruifujie offers specialized engineering support to integrate the central air condenser into your central air conditioning or chiller system. Send us your target cooling capacity, compressor model specifications, and ambient operating requirements to receive a complete technical evaluation and competitive quotation within 8 hours.
|
|
