10HP Original Refrigeration Condensing Units / Air-Cooled Unit 4VES-10Y

Name: 10HP Original Refrigeration Condensing Units / Air-Cooled Unit 4VES-10Y
Brand: RFJ Brand
SKU: 4VES-10Y
Rating: 5 (130 reviews)

Large Image : 10HP Original Refrigeration Condensing Units / Air-Cooled Unit 4VES-10Y

Product Details:

Place of Origin:	SHENZHEN China
Brand Name:	RFJ Brand
Certification:	CE
Model Number:	4VES-10Y

Payment & Shipping Terms:

Minimum Order Quantity:	1piece
Price:	discussed
Packaging Details:	Standard wooden packaging
Delivery Time:	15-20 days
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	5000pcs

Contact Now

Detailed Product Description

Type:	Condensing Unit	Model Number:	4VES-10(Y)
Cooling Capacity::	19190W	Lubricated::	3GS Oil SUNISO SL32S
Refrigerant Gas:	R22/R404a	Voltage:	220V/380V
Application:	Freezer	Horse Power::	10 HP
Sunction Line:	28mm	Liquid Line::	16mm
Highlight:	ac condenser unit , air cooled condensing unit

10HP Original Condensing Unit/air-cooled unit 4VES-10Y

Product Description

Advantage

High efficiency, Good reliability, Low noise, Low vibration, No leakage.
Wide range of application : The Compressor uses R22 as refrigerant. R134a, R404a, R407b and R407c are also approved. R12 and R502 are not suggested due to the international environment protection requirement. The machine can be used at a low or high condensing temperature.
Excellent performance : The compressor has a scientific structure design, strictly chosen material and precise procession and it is strictly inspected. The factory has obtained the National Compulsory Products CCC Certification, the National Industrial Products Manufacture License, and the ISO9001:2008 International Quality Supervision System Certification.
Reliable safety device : The compressor is equipped with motor protector and discharge temperature monitor to prevent the overheat of the motor and the compressor and the operation beyond approved

Technical Parameter


Top Discharge Compressor Condensing Unit (U Type)
Product Description: 1.condensing unit was assembled completely,installation is not constraint by site,a little space occupation. 2.double coils for condenser,eliminating the loss of heat exchange. 3.on the design of top discharge,air circulation consistent with the principle of air flow,no reflow phenomenon and improve the efficiency of heat transfer. 4.with external rotor motor,low noise,low power,large air volume. 5.original compressor,inner of condensing unit with the perfect protection system.
Technical Parameters
performance Modle		RFJ030H(U)	RFJ040H(U)	RFJ050H(U)	RFJ060H(U)		performance Modle		RFJ080H(U)	RFJ100H(U)	RFJ120H(U)	RFJ1500H(U)
nominal power(HP)		3HP	4HP	5HP	6HP		nominal power(HP)		8HP	10HP	12HP	15HP
Norminal refrigerating capacity (KW)		5.05	6.05	8.00	10.20		Norminal refrigerating capacity (KW)		11.00	17.80	20.40	25.60
Motor power (W)		180W	250W	2*180W	2*250W		Motor power (W)		2*250W	2*450W	2*450W	2*600W
Dia of fan (mm)		Φ400	Φ450	Φ400	Φ450		Dia of fan (mm)		Φ450	Φ500	Φ500	Φ550
Number of electric motors (a)		1	1	2	2		Number of electric motors (a)		2	2	2	2
Air Voume (M3/H)		4500	4500	6220	6220		Air Voume (M3/H)		9000	13000	13000	16600
Import and export	In(mm)	Φ16	Φ16	Φ16	Φ22		Import and export	In(mm)	Φ22	Φ28	Φ28	Φ28
Import and export	Out (mm)	Φ10	Φ10	Φ12	Φ12		Import and export	Out (mm)	Φ12	Φ12	Φ16	Φ16
dimension(mm)	L(mm)	750	1000	1270	1270		dimension(mm)	L(mm)	1370	1410	1500	1700
	w(mm)	650	650	700	700			w(mm)	800	850	900	900
	820	820	820	920		920		1030	1130	1130
installation size(mm)	a(mm)	420	700	870	870		installation size(mm)	a(mm)	970	910	900	1100
installation size(mm)	b(mm)	720	720	770	770		installation size(mm)	b(mm)	860	910	960	1060

Note:1.above datas are on the base of condensing temperature is 40℃ ,evaporation temperature is -15℃ , 2.reserve the right of design modified without prior inform.


Box Type Compressor Condensing Unit Dimensions
Unit Model	A	B	C	D	H	H1	Installation bore
RFJ-BRA09M/60 RFJ-BRA06H/60	1050	750	700	850	1380	1500	4-θ13
RFJ-BRA12M/80 RFJ-BRA09H/80	1150	880	830	950	1500	1630	4-θ13
RFJ-BRA14M/100 RFJ-BRA10H/100	1370	880	830	1170	1600	1730	4-θ13
RFJ-BRA18M/120 RFJ-BRA12H/120	1450	950	900	1250	1600	1730	4-θ13
RFJ-BRA23M/160 RFJ-BRA15H/160	1610	950	900	1410	1600	1730	4-θ13
RFJ-BRA28M/200 RFJ-BRA20H/200	1710	950	900	1510	1650	1830	4-θ13
RFJ-BRA34M/240 RFJ-BRA25H/240	2120	1050	1050	1920	1780	1900	4-θ13
RFJ-BRA30H/270	2300	1050	1050	2100	1780	1900	4-θ13
RFJ-BRA44M/300 RFJ-BRA35H/300	2450	1050	1050	2250	1780	1900	4-θ13
