R404a Air Cooled Condensation Unit Cold Room Evaporator With Unit Cooler

R404a Air Cooled Condensation Unit Cold Room Evaporator With Unit Cooler
R404a Air Cooled Condensation Unit Cold Room Evaporator With Unit Cooler R404a Air Cooled Condensation Unit Cold Room Evaporator With Unit Cooler R404a Air Cooled Condensation Unit Cold Room Evaporator With Unit Cooler R404a Air Cooled Condensation Unit Cold Room Evaporator With Unit Cooler

Large Image :  R404a Air Cooled Condensation Unit Cold Room Evaporator With Unit Cooler

Product Details:
Place of Origin: China
Brand Name: RFJ
Certification: CE
Model Number: AD452R4F
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: discussed
Packaging Details: Customerized wooden Packing
Delivery Time: 7-10 days
Payment Terms: L/C, D/A, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000 pcs/Year
Detailed Product Description
Model NO: AD452R4F Type: Water-Cooled
Cooling Water: Cooling Water System Type: Closed System
Fans Species: Double-speed Fan Noise Level: Low
Application Fields: Food Processing Condition: New
Refrigerant: R22/R134 Color: White
Voltage: 220V Usage: Cold Room
Temperature: -25, -18, -5, 0 Transport Package: Customerized Packing
High Light:

air cooled condenser in refrigeration

,

air cooled condensing unit

R404a air cooled cold room evaporator with unit cooler



1,Product Description
Features:
1.High efficiency staggered fin pattern design
2.Optimized sine waved fin for high performance
3.Internal grooved tube for higher heat exchanger efficiency
4.Optimized circuiting for better evaporation
5.Optimized air flow to reach max. Capacity
6.Robust,state-of-the-art sheet metal design
7.Casing with white coating for corrosion protection
8.Dual drip tray design to avoid water condensation
9.Fin spacing optional for specific application
10.Dual fin spacing design is available for min. Frost
11.Tailor made unit cooler is available for special application
12.Specific fan motor for low temp. application, higher air flow, higher air throw
13.Optional defrost available (Electric, water & hot gas defrost)
14.Imported brand e-heaters applied for defrost
15.Distributor support design to avoid unexpected vibration
16.Special "Floating Tube" design for large unit cooler
17.SS or Al casing is available for certain models
18.Air jet for longer air throw is available for certain models
19.Available for CO2-DX unit cooler up to 40 bar
20.Provide customized brine air cooler



 AD duaI discharge cooIers


450mm             Fin Spacing 7mm acing 4.5mm
  Models AD452R4F AD452R6F AD453R4F AD453R6F AD454R6F
SC1 KW  Ta -10℃ R22 17.2 21 26.2 31.8 43.8
 Te -0℃ R404A 17.2 22.2 26.2 31 43
  Tube Length m 127 190 190 285 380
  Surface ㎡ 48.8 73.2 73.2 109.9 146.5
  Circuit Vol. dm³ 10 15 15 22.5 30
  Fan Mot.No. 2 2 3 3 4
  Air Flow m³/h 7200 6900 10800 10350 13800
  Air Throw m 12 12 12 12 12
  Fan Mot.Amper A 1.2 1.2 1.8 1.8 2.4
  Fan Mot.Power W 500 500 750 750 1000
  in Tube Inch. 1/2 5/8 5/8 7/8 7/8
  Out Tube Inch 7/8 11/8 11/8 13/8 13/8
  Net Weight kg 109 120 159 176 216
  Drawing No.





450mm             Fin Spacing 7mm acing 7mm
  Models AD452C4 AD452C6 AD453C4 AD453C6 AD454C6
SC2 KW  Ta 0℃ R22 10 11.8 14.8 19.4 24.8
 Te -8℃ R404A 10 11.4 14.6 19.2 26.6

SC1 KW Ta -10℃ R22 14.4 17.2 21.2 28 38.2
 Te -0℃ R404A 14.2 16.6 20.8 27.4 37.6
  Tube Length m 127 190 190 285 380
  Surface ㎡ 32.7 49.1 49.1 73.6 98.1
  Circuit Vol. dm³ 10 15 15 22.5 30
  Fan Mot.No. 2 2 3 3 4
  Air Flow m³/h 7600 7200 11400 10800 14400
  Air Throw m 12 12 12 12 12
  Fan Mot.Amper A 1.2 1.2 1.8 1.8 2.4
  Fan Mot.Power W 500 500 750 750 1000
  Electric Defrost A 10.9 Y 10.9 Y 16.4 Y 16.4 Y 21.8 Y
  Electric Defrost W 7200 7200 10800 10800 14400
  In Tube Inch. 1/2 1/2 5/8 7/8 7/8
  Out Tube Inch 7/8 7/8 11/8 13/8 13/8
  Net Weight kg 108 119 158 175 215
  Drawing No.




  AE UItra Iow ProfiIe cooIers


300mm               Finspcing3.5mm

  Models AE301A4F AE301A6F AE302A3F AE302A4F AE302A6F AE303A4F AE303A6F AE304A6F
   Ta -10℃ R22 2.3 2.7 3.9 4.7 5.5 7 8 9.4
 Te -0℃ R404A 2.3 2.8 3.9 4.7 5.5 7 8.1 9.5
  Tube Length m 13 19 19 26 39 39 58 71
  Surface ㎡ 6.3 9.5 9.5 12.6 18.9 18.9 28.4 34.7
  Circuit Vol. dm³ 1 1.5 1.5 2 3.1 3.1 4.6 5.6
  Fan Mot.No. 1 1 2 2 2 3 3 4
  Air Flow m³/h 1000 850 2160 2000 1700 3000 2550 3200
  Air Throw m 3 3 5 4 4 6 5 7
  Fan Mot.Amper A 0.42 0.42 0.84 0.84 0.84 1.26 1.26 1.68
  Fan Mot.Power W 85 85 170 170 170 255 255 340
  In Tube Inch. 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2
  Out Tube Inch 5/8 5/8 5/8 5/8 7/8 7/8 7/8 7/8
  Net Weight kg 13 16 19 22 28 32 40 52
  Drawing No.





300mm             Fin Spacing 7mm
  Models AE301C4 AE301C6 AE302C3 AE302C4 AE302C6 AE303C4 AE303C6 AE304C6
SC2  KW Ta 0℃ R22 1.3 1.6 2.2 2.6 3.2 4 4.9 5.9
-8℃ R404A 1.3 1.6 2.3 2.7 3.3 4.1 4.9 6
SC3 KW  Ta -18℃ R22 0.9 1.1 1.5 1.9 2.3 2.7 3.2 3.8
 Te -25℃ R404A 0.9 1.1 1.5 1.9 2.3 2.7 3.3 3.9


  Tube Length m 13 19 19 26 39 39 58 71
  Surface ㎡ 3.4 5 5 6.7 10.1 10.1 15.1 18.4
  Circuit Vol. dm³ 1 1.5 1.5 2 3.1 3.1 4.6 5.6
  Fan Mot.No. 1 1 2 2 2 3 3 4
  Air Flow m³/h 1150 1020 2500 2300 2040 3450 3060 4000
  Air Throw m 4 4 6 5 5 7 6 8
  Fan Mot.Amper A 0.42 0.42 0.84 0.84 0.84 1.26 1.26 1.68
  Fan Mot.Power W 85 85 170 170 170 255 255 340
  Electric Defrost A 4.5 6.8 9.1 9.1 13.6 13.6 20.5 24.5
  Electric Defrost W 1000 1500 2000 2000 3000 3000 4500 4500
  In Tube Inch. 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2
  Out Tube Inch 5/8 5/8 5/8 5/8 7/8 7/8 7/8 7/8
  Net Weight kg 13 16 19 22 28 32 40 52
  No.
