| Model Number: | D8DJ-600X |
| MOQ: | 1 |
| Price: | discussed |
| Delivery Time: | 1-7DAYS |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Cylinder count: | 8 | |
| Displacement [m³/h]: | 151 | |
| Weight [kg]: | 347 | |
| Oil charge [dm³]: | 7,7 | |
| Max. operating current [A]: | 91,6 | |
| Locked rotor current [A]: | 444 | |
| Power supply [V/~/Hz]: | 400V/3/50Hz |
| milimeters | inches | ||
| Suction line: | 2 5/8" | ||
| Discharge line: | 1 5/8" |
| tc te | -35 | -30 | -25 | -20 | -15 | -10 | -5 |
| 30 | 1.55 | 1.79 | 2.05 | 2.35 | 2.69 | 3.09 | 3.56 |
| 35 | 1.38 | 1.61 | 1.85 | 2.12 | 2.42 | 2.76 | 3.17 |
| 40 | - | 1.44 | 1.66 | 1.91 | 2.17 | 2.48 | 2.82 |
| 45 | - | 1.27 | 1.49 | 1.71 | 1.95 | 2.22 | 2.52 |
| 50 | - | - | 1.31 | 1.52 | 1.75 | 1.99 | 2.26 |
| 55 | - | - | - | 1.35 | 1.56 | 1.78 | 2.02 |
|
|
| Model Number: | D8DJ-600X |
| MOQ: | 1 |
| Price: | discussed |
| Packaging Details: | wooden packaging |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Cylinder count: | 8 | |
| Displacement [m³/h]: | 151 | |
| Weight [kg]: | 347 | |
| Oil charge [dm³]: | 7,7 | |
| Max. operating current [A]: | 91,6 | |
| Locked rotor current [A]: | 444 | |
| Power supply [V/~/Hz]: | 400V/3/50Hz |
| milimeters | inches | ||
| Suction line: | 2 5/8" | ||
| Discharge line: | 1 5/8" |
| tc te | -35 | -30 | -25 | -20 | -15 | -10 | -5 |
| 30 | 1.55 | 1.79 | 2.05 | 2.35 | 2.69 | 3.09 | 3.56 |
| 35 | 1.38 | 1.61 | 1.85 | 2.12 | 2.42 | 2.76 | 3.17 |
| 40 | - | 1.44 | 1.66 | 1.91 | 2.17 | 2.48 | 2.82 |
| 45 | - | 1.27 | 1.49 | 1.71 | 1.95 | 2.22 | 2.52 |
| 50 | - | - | 1.31 | 1.52 | 1.75 | 1.99 | 2.26 |
| 55 | - | - | - | 1.35 | 1.56 | 1.78 | 2.02 |
