Product Details:
Payment & Shipping Terms:
|
| Place Of Origin: | Belgium | Type: | Semi-hermetic Refrigeration Compressor |
|---|---|---|---|
| Application: | Refrigeration Parts | Horse Power: | 20HP |
| Refrigerant: | R404 R407C R134A | Cylinder Count: | 6 |
| Brand: | Copeland | Power Supply: | 380-420V/3/50Hz |
| High Light: | copeland semi hermetic compressor,refrigerator compressor |
||
|
brand
|
copeland
|
|
model
|
D3DA-75X
|
|
No of Cylinders
|
3
|
|
TYPE
|
copeland semi hermetic compressor
|
|
power source
|
380-420v
|
|
horse power
|
7.5
|
|
refrigerant
|
r404a R134A
|
|
Color Black
|
Black
|
|
MOQ
|
1
|
|
year
|
2016
|
| tc te | -35 | -30 | -25 | -20 | -15 | -10 | -5 |
| 30 | 35.56 | 38.19 | 40.81 | 43.29 | 45.51 | 47.34 | 48.65 |
| 35 | 35.86 | 38.85 | 41.87 | 44.78 | 47.45 | 49.77 | 51.61 |
| 40 | - | 39.30 | 42.75 | 46.11 | 49.28 | 52.12 | 54.50 |
| 45 | - | 39.49 | 43.38 | 47.23 | 50.92 | 54.30 | 57.26 |
| 50 | - | - | 43.70 | 48.07 | 52.29 | 56.25 | 59.82 |
| 55 | - | - | - | 48.55 | 53.35 | 57.91 | 62.12 |
| tc te | -35 | -30 | -25 | -20 | -15 | -10 | -5 |
| 30 | 539.48 | 707.15 | 900.50 | 1 120.65 | 1 368.71 | 1 645.80 | 1 953.04 |
| 35 | 510.80 | 683.24 | 881.66 | 1 107.20 | 1 360.96 | 1 644.07 | 1 957.64 |
| 40 | - | 650.52 | 854.60 | 1 086.11 | 1 346.16 | 1 635.87 | 1 956.36 |
| 45 | - | 606.85 | 817.19 | 1 055.26 | 1 322.18 | 1 619.08 | 1 947.07 |
| 50 | - | - | 767.29 | 1 012.51 | 1 286.89 | 1 591.56 | 1 927.63 |
| 55 | - | - | - | 955.73 | 1 238.16 | 1 551.18 | 1 895.93 |
| tc te | -35 | -30 | -25 | -20 | -15 | -10 | -5 |
| 30 | 1.55 | 1.79 | 2.05 | 2.35 | 2.69 | 3.09 | 3.56 |
| 35 | 1.38 | 1.61 | 1.85 | 2.12 | 2.42 | 2.76 | 3.17 |
| 40 | - | 1.44 | 1.66 | 1.91 | 2.17 | 2.48 | 2.82 |
| 45 | - | 1.27 | 1.49 | 1.71 | 1.95 | 2.22 | 2.52 |
| 50 | - | - | 1.31 | 1.52 | 1.75 | 1.99 | 2.26 |
| 55 | - | - | - | 1.35 | 1.56 | 1.78 | 2.02 |
| Cylinder count: | 3 | |
| Displacement [m³/h]: | 151 | |
| Weight [kg]: | 351 | |
| Oil charge [dm³]: | 7,7 | |
| Max. operating current [A]: | 64,5 | |
| Locked rotor current [A]: | 357 | |
| Power supply [V/~/Hz]: | 380-420V/3/50Hz |
| WHO can use: | Chiller /cold storage |
| FOR what displacement: | 151m3/h |
| Cylinder count | 8 |
| Weight | 351KG |
| Oil charge | 7.7dm3 |
| Max.operating current | 64.5A |
| Locked rotor current | 357A |
| Power supply | 380-420V/3/50Hz |
| Connections suction line | 2 5/8 inches |
| Connections discharge line | 1 5/8 inches |
| Package | Each unit pack in a ply wooden export case |
| Refrigerant | R134a |
| Size(L*W*H) | 835*590*670mm |
| Production Lead time: | 7-10 working days for available stock |
