| Model Number: | 4JE-22Y |
| MOQ: | 1 |
| Price: | discussed |
| Delivery Time: | 1-5days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Name | Value |
| Brand | |
| Modle | 4JE-22Y |
| Production Capacity | 1000 Piece/Pieces per Month |
| Place Of Original | Germany |
| Year | 2014 |
| Certification | VDE, TUV, UL and CE |
| Power kW | 22 |
| Cooling capacity | 27350 |
| Dimensions | 1050/600/910 |
| Mounting dimensions | 800/555 |
1. Universally applicable
One compressor version forR134A, R404A, R507A, R407c and R22.
For air-conditioning
For medium and low temperatureapplications.
2. Large application range
Low temperature refrigeration withR404A/R507A over a wide range without additional cooling possible;
Varicool for low temperature refrigeration with R22.
3. Identical compressors for HFC and HCFCrefrigerants, Different oil type only
4. Energy efficient
High cooling capacity and minimal energyrequirements throgh:
Highly efficient working valves
Minimal dead space
Efficient, large volume motor
5. Quiet and low vibration
6. Robust
7. Electronic compressor protection
8. Efficient capacity control.
9. We can supply more Semi-Hermetic Compressor models as below:
The advantage of the compressor:
Energy efficient
High-efficiency profile
Infinite or closely stepped capacity control
Optimum economiser operation
Universal
R134a, R407C and R22 (R404A, R507A upon request)
With and without economiser (ECO)
Flexible
Dual capacity control
Changeable between 4-stage and infinite capacity control-without retrofitting the compressor
Suction and discharge gas connections can be rotated in 90" increments
|
|
