| Model Number: | 4G-20.2Y-40P,4GE-23Y-40P |
| MOQ: | 1 |
| Price: | discussed |
| Delivery Time: | 1-7DAYS |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Specification | Value |
|---|---|
| Model No. | 4GE-20Y |
| Motor Size (HP) | 20 |
| Motor Version | 3 |
| Displacement Type (m³/h) | 84.6 |
| Oil Charge (dm³) | 4.5 |
| Voltage | 380-420V/3PH/50Hz or 440-480V/3PH/60Hz |
| No. of Cylinders | 4 |
| Refrigerant | R-22, R134, R410A |
| Certification | VDE, TUV, UL and CE |
| Weight (kg) | 192 |
| Place of Origin | Germany |
| Packing | Wooden Case |
| Model | Motor Version | Displacement (m³/h) | Cylinders | Oil Charge (dm³) | Weight (kg) | Suction Connection | Discharge Connection |
|---|---|---|---|---|---|---|---|
| 4HE-18(Y) | 2 | 73.7 | 4 | 4.0 | 190 | 1 1/8" | 1 5/8" |
| 4HE-25(Y) | 1 | 73.7 | 4 | 4.0 | 194 | 1 1/8" | 2 1/8" |
| 4GE-20Y | 3 | 84.6 | 4 | 4.5 | 192 | 1 1/8" | 2 1/8" |
| 4GE-23(Y) | 2 | 84.6 | 4 | 4.5 | 192 | 1 1/8" | 2 1/8" |
| 4GE-30(Y) | 1 | 84.6 | 4 | 4.5 | 206 | 1 1/8" | 2 1/8" |
| 4FE-25Y | 3 | 101.8 | 4 | 4.5 | 196 | 1 1/8" | 2 1/8" |
| 4FE-28(Y) | 2 | 101.8 | 4 | 4.5 | 207 | 1 1/8" | 2 1/8" |
| 4FE-35(Y) | 1 | 101.8 | 4 | 4.5 | 207 | 1 1/8" | 2 1/8" |
| 6JE-22Y | 3 | 95.3 | 6 | 4.75 | 213 | 1 3/8" | 2 1/8" |
| 6JE-25(Y) | 2 | 228 | - | - | - | - | - |
| 6JE-33(Y) | 1 | 231 | - | - | - | - | - |
| 6HE-25Y | 3 | 110.5 | 6 | 4.75 | 224 | 1 3/8" | 2 1/8" |
| 6HE-28(Y) | 2 | 228 | - | - | - | - | - |
| 6HE-35(Y) | 1 | 235 | - | - | - | - | - |
| 6GE-30Y | 3 | 126.8 | 6 | 4.75 | 228 | 1 3/8" | 2 1/8" |
| 6GE-34(Y) | 2 | 228 | - | - | - | - | - |
| 6GE-40(Y) | 1 | 238 | - | - | - | - | - |
| 6FE-40Y | 3 | 151.6 | 6 | 4.75 | 238 | 1 5/8" | 2 1/8" |
| 6FE-44(Y) | 2 | 241 | - | - | - | - | - |
| 6FE-50(Y) | 1 | 241 | - | - | - | - | - |
| 8GE-50(Y) | 2 | 185 | 8 | 5 | 342 | 1 5/8" | 3 1/8" |
| 8GE-60(Y) | 1 | 350 | - | - | - | - | - |
| 8FE-60(Y) | 2 | 221 | 8 | 5 | 361 | 2 1/8" | 3 1/8" |
| 8FE-70(Y) | 1 | 374 | - | - | - | - | - |
|
|
| Model Number: | 4G-20.2Y-40P,4GE-23Y-40P |
| MOQ: | 1 |
| Price: | discussed |
| Packaging Details: | wooden packaging |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Specification | Value |
|---|---|
| Model No. | 4GE-20Y |
| Motor Size (HP) | 20 |
| Motor Version | 3 |
| Displacement Type (m³/h) | 84.6 |
| Oil Charge (dm³) | 4.5 |
| Voltage | 380-420V/3PH/50Hz or 440-480V/3PH/60Hz |
| No. of Cylinders | 4 |
| Refrigerant | R-22, R134, R410A |
| Certification | VDE, TUV, UL and CE |
| Weight (kg) | 192 |
| Place of Origin | Germany |
| Packing | Wooden Case |
| Model | Motor Version | Displacement (m³/h) | Cylinders | Oil Charge (dm³) | Weight (kg) | Suction Connection | Discharge Connection |
|---|---|---|---|---|---|---|---|
| 4HE-18(Y) | 2 | 73.7 | 4 | 4.0 | 190 | 1 1/8" | 1 5/8" |
| 4HE-25(Y) | 1 | 73.7 | 4 | 4.0 | 194 | 1 1/8" | 2 1/8" |
| 4GE-20Y | 3 | 84.6 | 4 | 4.5 | 192 | 1 1/8" | 2 1/8" |
| 4GE-23(Y) | 2 | 84.6 | 4 | 4.5 | 192 | 1 1/8" | 2 1/8" |
| 4GE-30(Y) | 1 | 84.6 | 4 | 4.5 | 206 | 1 1/8" | 2 1/8" |
| 4FE-25Y | 3 | 101.8 | 4 | 4.5 | 196 | 1 1/8" | 2 1/8" |
| 4FE-28(Y) | 2 | 101.8 | 4 | 4.5 | 207 | 1 1/8" | 2 1/8" |
| 4FE-35(Y) | 1 | 101.8 | 4 | 4.5 | 207 | 1 1/8" | 2 1/8" |
| 6JE-22Y | 3 | 95.3 | 6 | 4.75 | 213 | 1 3/8" | 2 1/8" |
| 6JE-25(Y) | 2 | 228 | - | - | - | - | - |
| 6JE-33(Y) | 1 | 231 | - | - | - | - | - |
| 6HE-25Y | 3 | 110.5 | 6 | 4.75 | 224 | 1 3/8" | 2 1/8" |
| 6HE-28(Y) | 2 | 228 | - | - | - | - | - |
| 6HE-35(Y) | 1 | 235 | - | - | - | - | - |
| 6GE-30Y | 3 | 126.8 | 6 | 4.75 | 228 | 1 3/8" | 2 1/8" |
| 6GE-34(Y) | 2 | 228 | - | - | - | - | - |
| 6GE-40(Y) | 1 | 238 | - | - | - | - | - |
| 6FE-40Y | 3 | 151.6 | 6 | 4.75 | 238 | 1 5/8" | 2 1/8" |
| 6FE-44(Y) | 2 | 241 | - | - | - | - | - |
| 6FE-50(Y) | 1 | 241 | - | - | - | - | - |
| 8GE-50(Y) | 2 | 185 | 8 | 5 | 342 | 1 5/8" | 3 1/8" |
| 8GE-60(Y) | 1 | 350 | - | - | - | - | - |
| 8FE-60(Y) | 2 | 221 | 8 | 5 | 361 | 2 1/8" | 3 1/8" |
| 8FE-70(Y) | 1 | 374 | - | - | - | - | - |
