Horse Power 12.8HP Scroll Compressor R-410A Zp154kce-Tfd-522 50HZ Frequency
ac compressor
,commercial refrigeration compressor
ZP154KCE-TFD-522 ZP Scroll Compressor
| Brand Name: | |
| Model Number: | ZP154KCE-TFD |
| Type: | Refrigeration Compressor |
| Application: | Refrigeration Parts, Air Conditioning,High-Temp |
| Certification: | CE |
| Voltage: | 380V |
| Frequency: | 50HZ |
| Phase | 3 |
| Horse Power: | 13HP |
| Dimension: | 10.38(L)*11.23(W)*21.72(H) |
| Refrigerant: | R-410a |
Catalogue for Hot Sale Scroll Compressor ZP
| Model | Voltage | Phase | Displacement | Out put | Cooling Capacity | Input power | COP | Current | Weight |
| (V) | (m3/hr) | (HP) | (W) | (W) | (W/W) | (A) | (Kg) | ||
| ZP57K3E-PFJ | 220-240 | 1 | 9.44 | 4.8 | 13950 | 4650 | 3 | 24 | 41 |
| ZP57K3E-TFD | 380-420 | 3 | 9.44 | 4.8 | 13950 | 4650 | 3 | 8.1 | 41 |
| ZP61KCE-PFZ | 220-240 | 1 | 10.11 | 5 | 14800 | 4933 | 3 | 23.3 | 40 |
| ZP61KCE-TFD | 380-420 | 3 | 10.11 | 5 | 14700 | 4742 | 3.1 | 8.3 | 40 |
| ZP67KCE-PFZ | 220-240 | 1 | 10.96 | 5 | 16200 | 5400 | 3 | 25.7 | 40 |
| ZP67KCE-TFD | 380-420 | 3 | 10.96 | 5.6 | 16100 | 5194 | 3.1 | 9.1 | 40 |
| ZP72KCE-TFD | 380-420 | 3 | 11.68 | 6 | 17100 | 5700 | 3 | 9.8 | 40 |
| ZP83KCE-TFD | 380-420 | 3 | 13.43 | 7 | 19900 | 6419 | 3.1 | 11.7 | 40 |
| VP90KSE-TFP | 380 | 3 | 14.64 | 7.5 | 21900 | 6844 | 3.2 | 12.3 | 57 |
| VP103KSE-TFP | 380 | 3 | 16.83 | 9 | 25200 | 7875 | 3.2 | 13.6 | 60 |
| VP120KSE-TFP | 380 | 3 | 19.84 | 10 | 29300 | 9156 | 3.2 | 16.6 | 61 |
| VP137KSE-TFP | 380 | 3 | 22.16 | 11.5 | 32600 | 10188 | 3.2 | 17.8 | 61 |
| VP144KSE-TFP | 380 | 3 | 23.42 | 12 | 35400 | 10727 | 3.3 | 18.7 | 61 |
| ZP154KCE-TFD | 380-420 | 3 | 24.87 | 13 | 37300 | 11303 | 3.3 | 20.7 | 65 |
| ZP182KCE-TFD | 380-420 | 3 | 29.08 | 15 | 44000 | 13333 | 3.3 | 25.7 | 66 |
| ZP235KCE-TWD | 380-420 | 3 | 37.97 | 20 | 57000 | 17273 | 3.3 | 29.9 | 140 |
| ZP295KCE-TWD | 380-420 | 3 | 46.71 | 25 | 71500 | 21667 | 3.3 | 37.2 | 160 |
| ZP385KCE-TWD | 380-420 | 3 | 60.79 | 30 | 92500 | 28030 | 3.3 | 48.1 | 177 |
| ZP485KCE-TWD | 380-420 | 3 | 77.33 | 40 | 117000 | 35455 | 3.3 | 60.3 | 200 |
