13.2KW 5HP Ac Compressor ZPD61KCE-TFD-522
13.2KW Ac Compresso
,5HP Ac Compresso
,ZPD61KCE-TFD-522
Digital Compressor ZPD61KCE-TFD-522 for Air Conditioning
Product description:
Scroll Digital compressor increases HVAC system efficiency via capacity modulation and provide energy savings by precisely matching compressor output to your heating or cooling needs. This technology is perfect for buildings or rooms which experience widely varying loads or where tight temperature and humidity control are needed.
Maximum Allowable Pressure (PS)
Digital ZRD42 to ZRD81: Low Side PS 20bar(g) / High Side PS 29.5 bar(g)
Digital ZRD94 to ZRD125: Low Side PS 20bar(g) / High Side PS 32 bar(g)
Digital ZPD34 to ZPD91: Low Side PS 28 bar(g) / High Side PS 43 bar(g)
Digital ZPD103 to ZPD182: Low Side PS 29.5 bar(g) / High Side PS 45 bar(g)
Specification:
Horse Power: 5 hp
Ton: 5
Cooling capacity: 13.2KW
Displacement: 10.1m³/h
Oil quantity: 1.89L
Packing way: wooden package
Gross weight: 46kg
Gross dimension: 30*30*65cm
| Product name | digital scroll compressor |
| Model | ZPD61KCE-TFD-522 |
| Brand | |
| Application | HVAC |
| MOQ | 1 piece |
