| Model Number: | ZP72KCE-TFD-52E |
| MOQ: | 1 pieces |
| Price: | discussed |
| Delivery Time: | 3 days |
| Payment Terms: | T/T,Western Union,MoneyGram |
| Type | Hermetic scroll compressors |
| Series | ZP |
| Model | ZP72KCE-TFD-52E |
| Parameter | Value |
|---|---|
| Displacement [m³/h] | 11,7 |
| Sound power [dBA] | 75 |
| Sound pressure level [dB] | 64 |
| Net Weight [kg] | 39,9 |
| Gross Weight [kg] | 46 |
| Oil charge [dm³] | 1,8 |
| Maximum high pressure [bar] | 43 |
| Maximum standstill pressure [bar] | 28,0 |
| Maximum lowside temperature [°C] | 50 |
| PED category | 1 |
| Parameter | Value |
|---|---|
| Power supply [V/~/Hz] | 380-420V/3/50Hz |
| Locked rotor current [A] | 75,0 |
| Max. operating current [A] | 15,0 |
| Winding resistance [Ω] | 2,3 |
| Connection Type | Size |
|---|---|
| Suction connection with supplied sleeve | 7/8" |
| Discharge connection with supplied sleeve | 1/2" |
|
|
| Model Number: | ZP72KCE-TFD-52E |
| MOQ: | 1 pieces |
| Price: | discussed |
| Packaging Details: | wooden box |
| Payment Terms: | T/T,Western Union,MoneyGram |
| Type | Hermetic scroll compressors |
| Series | ZP |
| Model | ZP72KCE-TFD-52E |
| Parameter | Value |
|---|---|
| Displacement [m³/h] | 11,7 |
| Sound power [dBA] | 75 |
| Sound pressure level [dB] | 64 |
| Net Weight [kg] | 39,9 |
| Gross Weight [kg] | 46 |
| Oil charge [dm³] | 1,8 |
| Maximum high pressure [bar] | 43 |
| Maximum standstill pressure [bar] | 28,0 |
| Maximum lowside temperature [°C] | 50 |
| PED category | 1 |
| Parameter | Value |
|---|---|
| Power supply [V/~/Hz] | 380-420V/3/50Hz |
| Locked rotor current [A] | 75,0 |
| Max. operating current [A] | 15,0 |
| Winding resistance [Ω] | 2,3 |
| Connection Type | Size |
|---|---|
| Suction connection with supplied sleeve | 7/8" |
| Discharge connection with supplied sleeve | 1/2" |
