R410A 4H-15.2Y-40P 4HE-18Y-40P 15HP Cold Room Compressor

Name: R410A 4H-15.2Y-40P 4HE-18Y-40P 15HP Cold Room Compressor
Brand: Shenzhen Ruifujie Technology Co., Ltd.
SKU: 4H-15.2Y-40P,4HE-18Y-40P
Price: 856.00 USD
Availability: InStock

Model Number:	4H-15.2Y-40P,4HE-18Y-40P
MOQ:	1 piece
Price:	US$712-1000/PC
Delivery Time:	5-7 Days
Payment Terms:	T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Type:

Refrigeration Compressor

Application:

Refrigeration Parts

Certification:

ROHS, CE

Power:

15HP

Weight:

183 KG

Refrigerant:

R404 R407C R134A

Warranty:

1 Year

Power Source:

AC POWER

Packaging Details:

Standard Wooden Package

Supply Ability:

10000Pieces/Year

Highlight:

15HP Bitzer Reciprocating Compressor

R410A Bitzer Refrigeration Compressor

Product Description

R410A 4H-15.2Y-40P 4HE-18Y-40P 15HP Cold Room Compressor

Product Specifications

Model	Displ. @1450r/min (m³/h)	Cylinders	Oil charge (dm³)	Weight (Kg)	Discharge line (mm/in)	Suction line (mm/in)
2KES-05Y	4.06	2	1	43	12 / 1/2"	16 / 5/8"
2JES-07Y	5.21	2	1	43	12 / 1/2"	16 / 5/8"
2HES-1Y	6.51	2	1	44	12 / 1/2"	16 / 5/8"
2HES-2Y	6.51	2	1	45	12 / 1/2"	16 / 5/8"
2GES-2Y	7.58	2	1	45	12 / 1/2"	16 / 5/8"
2FES-2Y	9.54	2	1	45	12 / 1/2"	16 / 5/8"
2FES-3Y	9.54	2	1	47	12 / 1/2"	16 / 5/8"
4FES-3Y	18.1	4	2	82	16 / 5/8"	22 / 7/8"
4FES-5Y	18.1	4	2	86	16 / 5/8"	22 / 7/8"
4EES-4Y	22.7	4	2	84	16 / 5/8"	28 / 1 1/8"
4EES-6Y	22.7	4	2	86	16 / 5/8"	28 / 1 1/8"
4DES-5Y	26.8	4	2	86	22 / 7/8"	28 / 1 1/8"
4DES-7Y	26.8	4	2	89	22 / 7/8"	28 / 1 1/8"
4CES-6Y	32.5	4	2	91	22 / 7/8"	28 / 1 1/8"
4CES-9Y	32.5	4	2	91	22 / 7/8"	28 / 1 1/8"
4VES-6Y	34.7	4	2.6	129	22 / 7/8"	28 / 1 1/8"
4VES-7Y	34.7	4	2.6	129	22 / 7/8"	28 / 1 1/8"
4VES-10Y	34.7	4	2.6	139	22 / 7/8"	28 / 1 1/8"
4TES-8Y	41.3	4	2.6	134	28 / 1 1/8"	35 / 1 3/8"
4TES-9Y	41.3	4	2.6	134	28 / 1 1/8"	35 / 1 3/8"
4TES-12Y	41.3	4	2.6	414	28 / 1 1/8"	35 / 1 3/8"
4PES-10Y	48.5	4	2.6	139	28 / 1 1/8"	35 / 1 3/8"
4PES-12Y	48.5	4	2.6	139	28 / 1 1/8"	35 / 1 3/8"
4PES-15Y	48.5	4	2.6	147	28 / 1 1/8"	42 / 1 5/8"
4NES-12Y	56.2	4	2.6	141	28 / 1 1/8"	35 / 1 3/8"
4NES-14Y	56.2	4	2.6	141	28 / 1 1/8"	35 / 1 3/8"

Technical Specifications

Parameter	SI Units	Imperial Units
Displacement (1450 RPM 50 HZ)	73.7 m³/h	2599.2 CFH
Displacement (1750 RPM 60 HZ)	88.83 m³/h	3137.0 CFH
No. of cylinder × bore × stroke	4 × 70mm × 55mm	4 × 2.76inch × 2.17inch
Weight	183 kg	404 lb
Max pressure (LP/HP)	19/32 bar	275/464 psi
Connection suction line	42mm-1 5/8"	42mm-1 5/8"
Connection discharge line	28mm-1 1/8"	28mm-1 1/8"
Motor version	2	2
Starting current (Rotor locked)	97.0 A Y/158.0 A YY	176.0 A
Motor voltage	380-420V Y-3-50 HZ	440-480V Y-3-60 HZ UL
Max operating current	36.7 A	36.7 A

Product Details

Model Number

4H-15.2Y / 4HE-18Y

Motor Size

15 HP

Motor Version

Displacement

84.6 m³/h

Oil Charge

4.5 dm³

Voltage

380-420V/3PH/50Hz or 440-480V/3PH/60Hz

Number of Cylinders

Refrigerant

R134, R410A

Certification

VDE, TUV and CE

Weight

183 kg

Place of Origin

Germany

Packing

Wooden case

Product Images
