| Model Number: | 6FE-50Y-40P,6F-50.2Y-40P |
| MOQ: | 1 piece |
| Price: | US$712-1000/PC |
| Delivery Time: | 5-7 Days |
| Payment Terms: | T/T,Western Union,MoneyGram |
| Parameter | SI Units | Imperial Units |
|---|---|---|
| Displacement (1450 RPM 50 HZ) | 151.6 m³/h | 5353.7 CFH |
| Displacement (1750 RPM 60 HZ) | 183.07 m³/h | 6462.6 CFH |
| No. of cylinders × bore × stroke | 6 × 82mm × 55mm | 6 × 3.23" × 2.17" |
| Weight | 241 kg | 531 lb |
| Max pressure (LP/HP) | 19/32 bar | 275/464 psi |
| Connection suction line | 54mm-2 1/8" | 54mm-2 1/8" |
| Connection discharge line | 42mm-1 5/8" | 42mm-1 5/8" |
| Motor version | 1 | 1 |
| Starting current (Rotor locked) | 226.0 A Y/404.0 A YY | 425.0 A |
| Motor voltage | 380-420V PW-3-50 HZ | 440-480V Y-3-60 HZ UL |
| Max operating current | 96.2 A | 96.2 A |
|
|
| Model Number: | 6FE-50Y-40P,6F-50.2Y-40P |
| MOQ: | 1 piece |
| Price: | US$712-1000/PC |
| Packaging Details: | Standard Wooden Package |
| Payment Terms: | T/T,Western Union,MoneyGram |
| Parameter | SI Units | Imperial Units |
|---|---|---|
| Displacement (1450 RPM 50 HZ) | 151.6 m³/h | 5353.7 CFH |
| Displacement (1750 RPM 60 HZ) | 183.07 m³/h | 6462.6 CFH |
| No. of cylinders × bore × stroke | 6 × 82mm × 55mm | 6 × 3.23" × 2.17" |
| Weight | 241 kg | 531 lb |
| Max pressure (LP/HP) | 19/32 bar | 275/464 psi |
| Connection suction line | 54mm-2 1/8" | 54mm-2 1/8" |
| Connection discharge line | 42mm-1 5/8" | 42mm-1 5/8" |
| Motor version | 1 | 1 |
| Starting current (Rotor locked) | 226.0 A Y/404.0 A YY | 425.0 A |
| Motor voltage | 380-420V PW-3-50 HZ | 440-480V Y-3-60 HZ UL |
| Max operating current | 96.2 A | 96.2 A |
