Product Details:
Payment & Shipping Terms:
|
| Brand Name: | Copeland | Certification: | CE |
|---|---|---|---|
| Model Number: | Zb21kqe-pfj | Application: | Refrigeration Parts |
| Conditions: | Brand New | Nominal Power: | 3HP |
| Dimensions: | 242x242x383mm | Connection Code:: | 558 524 Brazing / 523 559 Rotalock |
| Weight (NW/GW): | 27KG | Type: | Refrigeration Compressor |
| High Light: | R134a Refrigeration Scroll Compressor,Zb21kqe-Pfj |
||
1. Product introduction
1. Name: Copeland scroll compressor
2. Size: ZB21KQE-PFJ-558
3. Place of origin: China(Mainland)
4. Certification: CE, UL, ROHS
| Top sale compressor copeland scroll r134a 2 ton single phase copeland compressor zb21kqe-pfj | ||||||||||||||||||||||
|
||||||||||||||||||||||
2. Product parameter(Specification)
| Model | ZB15KQ | ZB19KQ | ZB21KQ | ZB26KQ | ZB30KQ |
| ZB15KQE | ZB19KQE | ZB21KQE | ZB26KQE | ZB30KQE | |
| Model type | TFD | TFD | TFD | TFD | TFD |
| PFJ | PFJ | PFJ | PFJ | ||
| Horse Power(HP) | 2 | 2.5 | 3 | 3.5 | 4 |
| Displacement(m³/h) | 5.92 | 6.8 | 8.6 | 9.9 | 11.68 |
| RLA(A)TFD | 4.3 | 4.3 | 5.7 | 7.1 | 7.4 |
| RLA(A)PFJ | 11.4 | 12.9 | 16.4 | 18.9 | |
| Running Capacitor | 40/370 | 45/370 | 50/370 | 60/370 | |
| Crankcase heater power(W) | 70 | 70 | 70 | 70 | 70 |
| Exhaust pipe diameter(“) | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 |
| Inspiratory tube diameter(“) | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 |
| Height(mm) | 383 | 389 | 412 | 425 | 457 |
| Points of Installing size(mm) | 190*190(8.5) | 190*190(8.5) | 190*190(8.5) | 190*190(8.5) | 190*190(8.5) |
| Oil(L)(4GS) | 1.18 | 1.45 | 1.45 | 1.45 | 1.89 |
| Net Weight | 23 | 25 | 27 | 28 | 37 |
3. Product feature and applicatio
Copeland ZB21KQE PFJ 558 R404A Tube Scroll Compressor 3Hp 240V~50Hz. Copeland Scroll compressors are for air conditioning systems, covering ZF low temperature models.
4. Production details
| Product Name | Copeland scroll compressor |
| Model | ZB21KQE-PFJ-558 |
| Color | Black |
| Voltage | 220/240V |
| Frequency | 50Hz |
| Capacity | 18300 |
| Refrigerant | R404a |
| Horse power | 3HP |
