7.5HP ZH24KVE-TWD-526 R407c Refrigeration Compressor
7.5HP Industrial Refrigeration Compressor
,Zh24kve-Twd
5HP Zh Scroll Compressors ZH24KVE-TWD-526 Copelametic Compressor for Heat Pump
| Specification | Value |
|---|---|
| Type | Hermetic scroll compressors |
| Model | ZH24KVE-TWD-526 |
| Displacement [m³/h] | 20.9 |
| Sound power [dBA] | 83 |
| Sound power with sound shell [dBA] | 73 |
| Sound pressure level [dB] | 72 |
| Net Weight [kg] | 93 |
| Gross Weight [kg] | 100 |
| Oil charge [dm³] | 4 |
| Maximum high pressure [bar] | 32 |
| Maximum standstill pressure [bar] | 22.6 |
| Minimal lowside temperature [°C] | -35 |
| Maximum lowside temperature [°C] | 50 |
| PED category | 2 |
| Parameter | Value |
|---|---|
| Power supply [V/~/Hz] | 380-420V/3/50Hz |
| Locked rotor current [A] | 99 |
| Max. operating current [A] | 18.3 |
| Winding resistance [Ω] | 1.4 |
| Connection Type | Size |
|---|---|
| Suction connection with supplied sleeve | 1 3/8" |
| Discharge connection with supplied sleeve | 7/8" |
- Scroll axial and radial compliance for high reliability
- High efficiency and increased heating capacity
- High water temperature for all applications
- Low sound and low vibration level
- Tandem combination for superior seasonal efficiency
Compatible with ZH12K4E to ZH45K4E, ZH56K4E to ZH11M4E, ZH06KVE to ZH18KVE PFS-582, ZH04K1P to ZH19K1P series.
Refrigerant: R134a, R407C, R410a
Quiet Operation: ZH heating compressors have been designed for low sound levels, a specific requirement for indoor heat pumps.
High Efficiency: Scroll™ Compressors For Heating are designed for optimum operation and reliability of heat pumps connected to hydronic distribution systems for space heating and/or for the production of domestic hot water. These applications require reaching condensing temperatures as high as 65°C with high efficiency and reliability over a broad operating range. Features such as brazed fitting connections and special versions for the tandemization of compressors fit the requirements of heat pump systems.
