Name: | AC Compressor | Type: | Rotary Type Compressor |
---|---|---|---|
Application: | Refrigeration | Applicable In Dustries: | Condensing Unit; Beverage Factory; Refrigerated Industry |
Service: | 100% Original Brand New | Warranty: | 1 Year |
After-sales Service Provided: | Online Support | Color: | Black |
High Light: | secop bd35f rotary compressor hvac,r134a rotary compressor hvac,bd controller air conditioner rotary compressor |
Specification Of Refrigeration Compressor
Type | Rotary Type Compressor |
Model | BD35F |
Voltage | 12V/24V |
Refrigerant | R134a |
Displacement | 0.12 |
Cooling Capacity (Btu/h) | 577 |
Power (W) | 50 |
Oil Quantity (Type) | 5.1 (Polyolester) |
Net Weight | 4.5KG |
Technical Specifications:
Features:
1. Sufficient starting torque of the compressor motor to allow the motor to start at the pressure conditions
in the refrigeration system.
2. Sufficient breakdown torque to allow the motor to handle the load conditions at start up and during operation.
3. When the refrigeration system is in operation, the temperature in the compressor should not rise to levels
which could damage its components. Consequently, condensing and compression temperatures should be kept
as low as possible.
4. Precise dimensioning of the refrigeration system in question and careful evaluation of the operating conditions
of the compressor at expected maximum loads.
5. Sufficient cleanliness and low residual humidity in the circuit.
