Customizable Refrigerator Condenser Units 2-50 HP Semi Hermetic Condensing Unit

Refrigerator Condenser Units 2-50HP Semi Hermetic Condensing Unit
Air cooled Condensing Unit for cold storage room

Specifications:
A 2HP low-temperature semi-hermetic condensing unit using Bitzer compressors is designed for commercial refrigeration applications. Here are the general specifications for such a unit, though specific models may vary:

General Specifications:

1. Compressor:

   • Brand: Bitzer(Customizable)
   • Type: Semi-hermetic
   • Horsepower: 2HP
   • Displacement: Varies by model, typically around 10-15 m³/h
   • Refrigerant: Suitable for R404A, R507, R22, or other low-temperature refrigerants
   • Operating Temperature: Typically ranges from -25°C to -40°C

2. Condensing Unit:

   • Condensing Type: Air-cooled
   • Cooling Capacity: Approximately 4-7 kW (varies based on ambient conditions and refrigerant)
   • Voltage: Usually available in 220V/380V, 50Hz or 60Hz (depending on region)
   • Fan: High-efficiency axial fan(s)
   • Coil Material: Copper tubes with aluminum fins for efficient heat exchange
   • Number of Fans: Typically 1 or 2 fans, depending on model
   • Noise Level: Low noise, usually around 50-60 dB

3. Other Features:

   • Control System: Equipped with high and low-pressure switches, thermostat, and safety devices
   • Oil Separator: Included to improve efficiency and protect the compressor
   • Receiver: Liquid receiver included to store refrigerant
   • Expansion Valve: Thermostatic expansion valve fitted for efficient refrigerant control
   • Pressure Gauges: For monitoring suction and discharge pressures

4. Dimensions and Weight:

   • Size: According to different working conditions and sizes, customized multi-parallel connection can be supported
   • Weight: Around 100-150 kg, depending on the specific configuration

5. Applications:

   • Suitable for low-temperature storage, freezer rooms, cold storage, or other commercial refrigeration systems requiring temperatures down to -40°C.

If you need detailed specifications for a particular model, you can provide a specific Bitzer compressor model number, and I can help with more tailored data.
