Piston Type: | Scroll | Power Source: | AC Power |
---|---|---|---|
Configuration: | Stationary | Drive Mode: | Electric |
Horse Power: | 15HP | Temperature: | Med Temperature |
Refrigerant: | R404a | Sightglass: | Compressor With Sightglass |
Qty/one Pallet: | 16pcs | Voltage: | 380V/50HZ |
Application: | Middle Refrigeration,-25 Dgree To 5 Degree | Weight: | 63KG |
Electric Current: | 174A | Displacemint: | 43.3 |
Dimensions: | 264*285*553CM | Exhaust Pipe: | 7/8 |
Admission Pipe: | 1 3/8 | ||
Highlight: | copeland ac compressor,commercial refrigeration compressor |
15hp High Efficiency Scroll Type Compressor Zb114kqe - Tfd - 551
Specifications:
1, Copeland Scroll Compressor ZB114KQE-TFD-551
Copeland:
1. All models on sale
2. Competitive Price
3. Continuous Supply Capacity
Copeland Features:
1. Low energy consumption
2. Stable operating
3. Easy to dismantle and install
Description:
Copeland Scroll Digital® Technology for simple, step-less capacity modulation.
Applications:
The ZB series is optomized for high and medium temperature applications in the right choise for:
1. Medium temperature:Cold rooms,beverage cooling, vegetable cooling,display cases,plastic molding.
2. High temperature: Process cooling,milk production,grain drying, food preparation areas,flower preservation.
We can supply more ZB models as below
No |
Model |
Qty/Pallet |
Refrigerant |
1 |
ZB15KQ-PFJ-558-2HP/R22 |
16 |
R22 |
2 |
ZB15KQ-TFD-558-2HP/R22 |
16 |
R22 |
3 |
ZB21KQ-PFJ-558-3HP/R22 |
16 |
R22 |
4 |
ZB21KQ-TFD-558-3HP/R22 |
16 |
R22 |
5 |
ZB26KQ-PFJ-558-3.5HP/R22 |
16 |
R22 |
6 |
ZB26KQ-TFD-558-3.5HP/R22 |
16 |
R22 |
7 |
ZB29KQ-TFD-558-4HP/R22 |
16 |
R22 |
8 |
ZB38KQ-TFD-558-5HP/R22 |
16 |
R22 |
9 |
ZB45KQ-TFD-558-6HP/R22 |
16 |
R22 |
10 |
ZB48KQ-TFD-558-7HP/R22 |
16 |
R22 |
11 |
ZB58KQ-TFD-551-8HP/R22 |
12 |
R22 |
12 |
ZB66KQ-TFD-551-9HP/R22 |
12 |
R22 |
13 |
ZB76KQ-TFD-551-10HP/R22 |
12 |
R22 |
14 |
ZB88KQ-TFD-551-12HP/R22 |
12 |
R22 |
15 |
ZB114KQ-TFD-551-15HP/R22 |
12 |
R22 |
16 |
ZB15KQE-PFJ-558-2HP/R404 |
16 |
R404 |
17 |
ZB15KQE-TFD-558-2HP/R404 |
16 |
R404 |
18 |
ZB19KQE-PFJ-558-2.5HP/R404 |
16 |
R404 |
19 |
ZB19KQE-TFD-558-2.5HP/R404 |
16 |
R404 |
20 |
ZB21KQE-PFJ-558-3HP |
16 |
R404 |
21 |
ZB21KQE-TFD-558-3HP |
16 |
R404 |
22 |
ZB26KQE-TFD-558-3.5HP |
16 |
R404 |
23 |
ZB26KQE-PFJ-558-3.5HP |
16 |
R404 |
24 |
ZB29KQE-TFD-558-4HP |
16 |
R404 |
25 |
ZB38KQE-TFD-558-5HP |
16 |
R404 |
26 |
ZB45KQE-TFD-558-6HP |
16 |
R404 |
27 |
ZB48KQE-TFD-558-7HP |
16 |
R404 |
28 |
ZB58KQE-TFD-551-8HP |
12 |
R404 |
29 |
ZB66KQE-TFD-551-9HP |
12 |
R404 |
30 |
ZB76KQE-TFD-551-10HP |
12 |
R404 |
Model NO. |
Cindensate Temperature |
The Evaporation Temperature ° C (R22/50HZ) |
|||||
-12 |
-10 |
-5 |
0 |
5 |
10 |
||
ZB15KQ |
40 |
3300 |
3550 |
4350 |
5200 |
6250 |
7400 |
ZB19KQ |
40 |
3650 |
3950 |
4850 |
5850 |
7000 |
8300 |
ZB21KQ |
40 |
4650 |
5050 |
6200 |
7450 |
8850 |
10500 |
ZB26KQ |
40 |
5100 |
5500 |
6800 |
8200 |
9850 |
11700 |
ZB29KQ |
40 |
6230 |
6790 |
8290 |
9970 |
11800 |
14070 |
ZB38KQ |
40 |
7300 |
8000 |
9950 |
12200 |
14650 |
17300 |
ZB45KQ |
40 |
9400 |
10200 |
12400 |
14900 |
17800 |
21000 |
ZB48KQ |
40 |
10390 |
11285 |
13700 |
16436 |
19574 |
23199 |
ZB58KQ |
40 |
11800 |
12950 |
16100 |
19600 |
19574 |
28000 |
ZB66KQ |
40 |
13950 |
15100 |
18400 |
22200 |
26500 |
31500 |
ZB76KQ |
40 |
16400 |
17800 |
21700 |
28500 |
30500 |
35500 |
ZB88KQ |
40 |
18800 |
20400 |
24900 |
30000 |
36000 |
42000 |
ZB95KQ |
40 |
19500 |
21400 |
26500 |
32000 |
38200 |
45200 |
ZB114KQ |
40 |
23200 |
25500 |
31700 |
38500 |
41600 |
54500 |
Model NO. |
Cindensate Temperature |
The Evaporation Temperature ° C (R404/50HZ) |
||||||
-25 |
-20 |
-15 |
-10 |
-5 |
0 |
5 |
||
ZB15KQE |
40 |
1870 |
2430 |
3000 |
3700 |
4450 |
5350 |
6350 |
ZB19KQE |
40 |
2490 |
3050 |
3750 |
4550 |
5450 |
6500 |
7700 |
ZB21KQE |
40 |
3000 |
3700 |
4550 |
5000 |
6600 |
7900 |
9350 |
ZB26KQE |
40 |
3500 |
4300 |
5250 |
6350 |
7650 |
9100 |
10800 |
ZB29KQE |
40 |
4070 |
5040 |
6160 |
7460 |
8960 |
10680 |
12650 |
ZB38KQE |
40 |
5100 |
6250 |
7700 |
9300 |
11200 |
13350 |
15800 |
ZB45KQE |
40 |
6000 |
7400 |
9050 |
10950 |
13150 |
15700 |
18600 |
ZB48KQE |
40 |
6579 |
8150 |
9969 |
12074 |
14500 |
17287 |
20471 |
ZB58KQE |
40 |
7050 |
9250 |
11700 |
14400 |
17500 |
21000 |
24900 |
ZB66KQE |
40 |
8900 |
11100 |
13500 |
16400 |
19600 |
23400 |
27600 |
ZB76KQE |
40 |
10900 |
13300 |
16100 |
19400 |
23300 |
27800 |
33000 |
