Semi Hermetic 9hp Compressor All Models R404a 4CES-9Y-40S 4CC-9.2Y-40S 11.3kw

Name: Semi Hermetic 9hp Compressor All Models R404a 4CES-9Y-40S 4CC-9.2Y-40S 11.3kw
Brand: Shenzhen Ruifujie Technology Co., Ltd.
SKU: 4CES-9Y-40S,4CC-9.2Y-40S
Price: 10000 USD
Availability: InStock

Model Number:	4CES-9Y-40S,4CC-9.2Y-40S
MOQ:	1
Price:	Discussed
Delivery Time:	30 days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE 3C

Place Of Origin:

Germany

Type:

Refrigeration Compressor

Application:

Refrigeration Parts

Max Operating Curr:

Nt: 20.2A

Model:

4CES-9Y

Voltage:

380v-420v /3 Ph / 50Hz

Refrigerant:

R407c/r404a

Horse Power(hp):

9HP

Max. Power Input:

11.3kw

Displacement(m3/:

32.48

Max. Pressure (LP/:

19/32 Bar

Net Weight:

90.5kg

Packaging Details:

wooden boxes

Supply Ability:

1000 pieces

Highlight:

air cooled condenser unit

air cooled condensing unit

Product Description

Semi Hermetic 9hp Compressor All Models R404a 4CES-9Y-40S 4CC-9.2Y-40S 11.3kw

Product Overview

Semi-hermetic 9hp compressor available in all models including R404a 4CES-9Y-40S and 4CC-9.2Y-40S configurations.

Standard Configuration

Cold room condensing unit
Compressor with crankcase heater
Oil pressure safety switch (except octagon compressor)
Shell and tube type condenser
Dryer filter and gauge panel
B5.2 refrigeration oil
Shielding gas
Low-temperature compressor with cooling fan
Double-stage compressor with intercooler

Key Features

High quality components from world famous brands
Effective shell and tube type condenser for high energy efficiency ratio
Water cooled packaged unit design
Compact structure, sturdy and durable construction
Convenient installation process
Wide compatibility with refrigerants R22, R134a, R404a, R507a, etc.

Technical Specifications

Overall Dimensions

Condensing Unit Model	Compressor Model	Length L(A) (mm)	Width W(B) (mm)	Height H(C) (mm)
SPB03WL	2CES-3Y	1010	350	720
SPB04WL	4EES-4Y	1010	350	720
SPB05WL	4DES-5Y	1080	350	760
SPB06WL	4CES-6Y	1080	350	760
SPB09WL	4TES-9Y	1120	350	800
SPB12WL	4PES-12Y	1120	350	800
SPB14WL	4NES-14Y	1220	400	850
SPB18WL	4HE-18Y	1220	400	850
SPB23WL	4GE-23Y	1320	400	950
SPB28WL	6HE-28Y	1620	400	950
SPB34WL	6GE-34Y	1620	400	950
SPB44WL	6FE-44Y	1900	400	1000

Installation Dimensions

Condensing Unit Model	Compressor Model	Length L(D) (mm)	Width W(E) (mm)	Installation Bore
SPB03WL	2CES-3Y	780	300	Φ18
SPB04WL	4EES-4Y	780	300	Φ18
SPB05WL	4DES-5Y	850	300	Φ18
SPB06WL	4CES-6Y	850	300	Φ18
SPB09WL	4TES-9Y	890	300	Φ18
SPB12WL	4PES-12Y	890	300	Φ18
SPB14WL	4NES-14Y	890	350	Φ18
SPB18WL	4HE-18Y	990	350	Φ18
SPB23WL	4GE-23Y	1080	350	Φ18
SPB28WL	6HE-28Y	1400	350	Φ18
SPB34WL	6GE-34Y	1400	350	Φ18
SPB44WL	6FE-44Y	1680	350	Φ18

Note: We reserve the right to modify the above overall and installation sizes without prior notice.

Packaging & Shipping

Export packaging tailored to product dimensions
Carton and free-fumigation wooden pallet
Complete free-fumigation wooden case available
Shipping typically effected 25-30 days after order placement

Our Services

One year warranty for complete machine and one year for compressors
Pre-sale services:
- Customer operation condition analysis
- Equipment selection and consultation
After-sales services:
- Compressor refrigeration condensing unit and racks design engineering
- Installation guidance and technical proposals
- On-site equipment testing with overseas engineer availability
